| Model Number: | SBG-B 0.5-3t) |
|---|---|
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Shear beam type :
Application: Widely used for moter vehicles, ground weighter,single-track scales, hopper weighing,metering equipment,platform scales.
Technical Parameter
|
Rated Load |
0.5t, 1t, 2t, 3t |
|
Rated Output |
2.0000±0.001mV/V |
|
Total Error |
±0.02%F.S |
|
Recommended Excitation Voltage |
5V～12V(AC or DC) |
|
Maximum Excitation Voltage |
15V(AC or DC) |
|
Zero Balance |
±1% F.S |
|
Input Impedance |
380±5Ω |
|
Output Impedance |
350±2Ω |
|
Insulation Impedance |
≥3000MΩ |
|
Safe Overload |
150%F.S |
|
Ultimate Overload |
200%F.S |
|
Operating TemperatureRange |
(-30～+70)℃ |
|
CompensatedTemperatureRange |
(-20～+60)℃ |
|
Temperature Effect On Load |
±0.02%F.S/10℃ |
|
Temperature Effect On Zero |
±0.02%F.S/10℃ |
|
Construction |
Alloy Steel |
|
Protection Class |
IP67 |
|
Citation |
GB/T7551-2008/OIML R60 |
|
Mode of Connection |
Input+:Red |
