Type: | Inkjet Printer |
---|---|
After-sales Service Provided: | Engineers available to service machinery overseas |
Certification: | CE |
Weight: | 70kg |
Dimensions(L*W*H): | 930 x 730 x 63 MM |
Gross Power: | 35W |
Voltage: | 110/220V |
Color & Page: | Multicolor |
Automatic Grade: | Automatic |
Usage: | Cloths Printer,multi-function flatbed printer |
Model Number: | ES-T330C6S(A3)-B |
Brand Name: | Esshion |
Place of Origin: | China (Mainland) |
Plate Type: | Flatbed Printer |
Condition: | New |
Max. Printing size: | 12.95*18.90 inch (329*480mm) |
Max. Printing Height: | 80 mm |
Resolution: | 5760*1440 dpi |
Quick Details
Specifications
- Super A3+ printing size: 329*480mm.
- High resolution: 5760*1440DPI.
- Max printing thickness: 80mm.
- T-shirt, fabric; promotion items(medals, photo frames, package printing, leather, customized gifts), signage(home decoration), phone and pad case
- 6 colors with high and sharp color performances.
- Continuous ink supply system. Easy to refill the inks.
- Direct printing on various materials.
- Compatible with common software, i. E: ps/cd/aucad.
- USB ports connection.
- Low cost customized gifts printing.
- Automatic height measurement and stop.
Heat transfer and silk screen Inkjet printing onto garments is no longer a good choice and came out of date with the digital printing technology development. Over the last few years the prints have become much more durable and the quality and wash-ability is now equal to and even better than screen printing.
From short runs or even one-off prints to large production runs, the Esshion T-shirt printer has been proven by large and small companies choose over and over again.
T-shirt Printer is being used by everyone from home based businesses, to retail stores, screen printers, embroiders - all the way to large internet companies with dozens of "banks" of machines doing thousands of shirts per day! It is a very robust production machine that prints outstanding images on light and dark shirts!
This T-Shirt Printer is great for small and large jobs. With an ink cost of less than 20 cents per shirt (standard print size on light shirts) and speeds of 60 to 80 seconds for a standard size image you can get great production! This T-Shirt Printer uses four color plus white(CMYK+WWWW) inkjet technology to give you outstanding vibrant prints on light and dark garments. You can print from most graphic programs like Photoshop, Illustrator and Corel draw, or you can create the artwork and print from our RIP software.
Esshion T-shirt printer prints are very wash fast. The finished print needs to be heat-set using either a standard heat transfer press or long conveyor dryer. No additional treatment is necessary (other than applying pretreatment for white ink on dark shirts). The Esshion T-shirt Printer line of printers gives you far more value and useful service life than cheaper/less expensive printers that use home based print engineers. This T-Shirt printers line uses the powerful commercial Epson 1390 as the print engine. It is designed to run 24/7 day-in and day-out!
Printing method |
Micro PIEZO Technology |
Max print size |
329*480 MM |
Printer head |
EPSON 1390 |
Print resolution |
5760*1440 dpi |
Print quality |
True Photographic quality |
Printing Direction |
Smart Bi-directional Printing Mode |
Printing speed |
111 seconds/A4 size. |
Printing method |
Continuous Production |
Max Media thickness |
80 MM |
Max Media weight |
10 KGs NET. |
Operating system |
Windows 95/98/XP/ME/Vista/NT/MAC |
Interface |
USB port |
Languages |
English, Chinese. |
Ink colors |
C, M, Y, K, LC, LM or C, M, Y, K, W, W. |
Ink type |
Multifunctional Ink / Textile Ink / Specialized ink |
Ink system |
CISS built inside |
Ink supply |
100 ml/bottle |
Height Adjustment |
Automatic with sensor. |
Driving Power |
110 V/ 220 V. |
Power consumption |
35 W/ Hour. |
Ink consumption |
12 ML/SQM. |
Working environment |
10-35 degrees. |
Software |
Photoshop, CorelDraw, Illustrator, BR RIP, |
Package size L*W*H |
930 x 730 x 63 MM |
Net Weight |
47 KGs |
Gross Weight |
70 KGs with wooden box |
Media feeding system |
Manual |
Packing |
Wooden box |
