| Moving Type: | Wheel Loader |
|---|---|
| Type: | Backhoe Loader |
| Place of Origin: | United States |
| Model Number: | 580M |
| Brand Name: | CASE |
| Condition: | Used |
| Make: | CASE |
| Year: | 2007 |
Quick Details
Specifications
Used Case Backhoe Loader case 580M/ cat 910 928g 938g 950e 950f 96e 966g
Specification
Product Stock List
Specification
| Engine | ||
| Make | Case | |
| Model | Family III 445/M2, Tier II certified | |
| Gross Power | 80 hp | 60 kw |
| Net Power | 76 hp | 57 kw |
| Displacement | 272 cu in | 4.5 L |
| Power Measured @ | 2200 rpm | |
| Torque Measured @ | 1400 rpm | |
| Net Torque Rise | 23 % | |
| Number of Cylinders | 4 | |
| Net Max Torque | 231 lb ft | 314 Nm |
| Aspiration | Natural | |
| Operational | ||
| Operating Weight 2wd | 13359 lb | 6060 kg |
| Max Weight | 16510 lb | 7489 kg |
| Fuel Capacity | 31.4 gal | 119 L |
| Hydraulic System Fluid Capacity | 28 gal | 106 L |
| Oil System Fluid Capacity | 3.6 gal | 13.6 L |
| Cooling System Fluid Capacity | 4.5 gal | 16.8 L |
| Transmission Fluid Capacity | 5.5 gal | 20.8 L |
| Front Axle Fluid Capacity | 1.5 gal | 5.5 L |
| Rear Axle Fluid Capacity | 3.8 gal | 14.2 L |
| Turning Radius | 11 ft in | 3350 mm |
| Tire Size Front - 2wd / 4wd | 11Lx16.1/12x16.5 | |
| Rear Tires Size 2wd/4wd | 17.5Lx24/19.5Lx24 | |
| Operating Voltage | 12 V | |
| Alternator Supplied Amperage | 90 amps | |
| Transmission | ||
| Type | 4-speed synchromesh with hydraulically actuated clutches | |
| Number of Forward Gears | 4 | |
| Number of Reverse Gears | 4 | |
| Max Speed - Forward | 24.5 mph | 39.4 km/h |
| Max Speed Reverse | 29.6 mph | 47.6 km/h |
| Backhoe | ||
| Dig Depth - Std | 14.3 ft in | 4340 mm |
| Dig Depth - Ext | 18.3 ft in | 5560 mm |
| Reach From Swivel - Std | 17.8 ft in | 5440 mm |
| Reach From Swivel - Ext | 21.8 ft in | 6650 mm |
| Bucket Dig Force - Std | 11212 lb | 5085.7 kg |
| Bucket Dig Force - Ext | 11212 lb | 5085.7 kg |
| Load at Max Lift - Std | 1950 lb | 885 kg |
| Load at Max Lift - Ext | 810 lb | 367 kg |
| Load Height - Std | 11.2 ft in | 3400 mm |
| Load Height - Ext | 13.3 ft in | 4040 mm |
| Reach at Load Height - Std | 8.8 ft in | 2670 mm |
| Reach at Load Height - Ext | 11.5 ft in | 3500 mm |
| Loader | ||
| Bucket Capacity | 0.87 yd3 | 0.67 m3 |
| Bucket Width | 82 in | 2080 mm |
| Bucket Breakout Force | 9164 lb | 40.8 kN |
| Lift Capacity at Full Height | 6182 lb | 2804 kg |
| Clearance at Max Dump Height | 8.7 ft in | 2640 mm |
| Reach at Max Dump Height | 28.2 ft in | 717 mm |
| Dig Depth | 7.8 in | 199 mm |
| Hydraulic | ||
| Pump Type | gear-type, transmission driven | |
| Pump Flow Capacity | 28.5 gal/min | 108 L/min |
| Relief Valve Pressure | 3050 psi | 146 kPa |
| Dimensions | ||
| Transport Length | 23.2 ft in | 7070 mm |
| Transport Width | 7.2 ft in | 2180 mm |
| Transport Height | 11.3 ft in | 3420 mm |
| Height to Top of Cab | 8.9 ft in | 2720 mm |
| Wheelbase | 7 ft in | 2150 mm |
| Ground Clearance | 1.2 ft in | 376 mm |
