1.Application

   Column type load cell, hermetically sealed structure

   Compression load cell,  IP67 &IP68, fast dynamic response

   This type load cell is simple to install, easy to use

   This type load cell is suitable for electronic truck scale, track scale and other electronic weighing devices.

2.

Technical Parameter
Rated Load	10t,20t,25t,30t,40t
Sensitivity	2.0000±0.001mV/V
Total Error	±0.02%F.S
Creep(30minutes)	±0.02%F.S
Recommended Excitation Voltage	5V～18V(AC or DC)
Maximum Excitation Voltage	24V(AC or DC)
Zero Balance	±1%F.S
Input Impedance	380±5Ω
Output Impedance	350±2Ω
Insulation Impedance	≥5000MΩ
Safe Overload	150%F.S
Ultimate Overload	200%F.S
Operating Temperature Range	(-30～+70)℃
Compensated Temperature Range	(-20～+60)℃
Temperature Effect On Load	±0.02%F.S/10℃
Temperature Effect On Zero	±0.02%F.S/10℃
Construction	Alloy Steel
Protection Class	IP67&IP68
Citation	GB/T7551-2008/OIML R60
Mode of Connection	Input+:Red Input-:Black Output+:Green Output-:White
