| Application: | Laser Cutting |
|---|---|
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Certification: | CE |
| Model Number: | HQ1410M |
| Brand Name: | HONG QIANG |
| Place of Origin: | China (Mainland) |
| Graphic Format Supported: | AI,BMP,DST,DWG,DXF,DXP,LAS,PLT |
| Control Software: | RDWorks |
| Cooling Mode: | Water Cooling |
| CNC or Not: | Yes |
| Cutting Speed: | 25-25,000MM/MIN. |
| Cutting Area: | 1400*1000MM |
| Cutting Thickness: | 3 MM STAINLESS STEEL, 20mm MDF Wood board |
| Applicable Material: | Acrylic,Crytal,Glass,Leather,MDF,Metal,Paper,plastic,Plexiglax,Plywood,Rubber,Stone,Wood |
| Laser Type: | CO2 |
| Condition: | New |
| 1400*1000MM: | HQ1410 |
Quick Details
Specifications
Max.working area: As client's requirement.
Max. working speed: 25m/min.
X/Y Locating Precision: 0.1mm
X/Y Repeat Locating Precision: +/-0.1mm
Voltage:220V±10%50Hz 110v60hz
Laser power: 100W 130w 150w 200W
Max. power: <2.5KVA
Operating Temperature: 5-40 degree
Graphic Format Supported: CDR,BMP,PLT,GPEJ,DXF,DST
Available Materials: Carbon Steel,Stainless Steel (0.2-2mm), Acrylic, wood, bamboo, textile, leather, glass, crystal, plexiglass, marble,
granite, stone, plastic, chinaware etc.
Max. working speed: 25m/min.
X/Y Locating Precision: 0.1mm
X/Y Repeat Locating Precision: +/-0.1mm
Voltage:220V±10%50Hz 110v60hz
Laser power: 100W 130w 150w 200W
Max. power: <2.5KVA
Operating Temperature: 5-40 degree
Graphic Format Supported: CDR,BMP,PLT,GPEJ,DXF,DST
Available Materials: Carbon Steel,Stainless Steel (0.2-2mm), Acrylic, wood, bamboo, textile, leather, glass, crystal, plexiglass, marble,
granite, stone, plastic, chinaware etc.
