Loa: 67.60m Lbp 63.50m Breadth MLD 14.00m
Depth MLD 4.80m Light draft 1.45m Loading draft 3.95m
Navigation area coastal Hopper capacity Abt.1500m3 Loading displacement 3163.58t
Light displacement 721.08t Working area: A1+A2
Hull material Steel/40mm
Type:Speke Weight 1596kg Quantity 2
Chain diameter: Diameter 34mm Length 220m
Winlass
Quantity 2 Rudder area:4.20m2 RudderStock diameter 160mm
Working type electric-hydraulic Type Streamline
Model: 8170ZCA-3 Quantity 2 Date June.7.2011
Power: 601KW Rated speed: 1350r/min
Maker Weichai power co.,ltd
Model: WHG600 quantity 2
Reduction 5:01 Capcatity:0.440kw/r/min
Maker Hazhou.,ltd
Propller Dia:2100mm Material cast steel
Quantity 2 Type FPP
