| Output: | Analog Sensor |
|---|---|
| Theory: | Resistance Sensor |
| Usage: | Pressure Sensor |
| Model Number: | PA-618 |
| Brand Name: | ZP |
| Place of Origin: | China (Mainland) |
| Material: | aluminum |
| Cap: | 5kg,8kg,10kg,15kg,20kg,30kg,35kg,100kg |
Quick Details
Specifications
1.Capacity(kg) :5,8,10,15,20,30,35,100
Features: Sensor elastomer aluminum alloy material; colorless anodized; sealant;
Applications: Widely used in electronic price scale, weight scales and other small table electronic scales.
Recommended table size: 200 × 200mm
2.
| Technical Parameter | |
| Rated Load | 5kg,8kg,10kg,15kg,20kg,30kg,35kg,100kg |
| Rated Output | 2.0000±0.1mV/V |
| Total Error | ±0.02%F.S |
| Creep(30minutes) | ±0.02%F.S |
| Recommended Excitation Voltage | 9V~12V(DC) |
| Maximum Excitation Voltage | 15V(AC or DC) |
| Zero Balance | ±1.0%F.S |
| Input Impedance | 405±10Ω |
| Output Impedance | 350±3Ω |
| Insulation Impedance | ≥5000MΩ(100VDC) |
| Safe Overload | 120%F.S |
| Ultimate Overload | 150%F.S |
| Operating Temperature Range | (-20~+60)℃ |
| Compensated Temperature Range | (-10~+40)℃ |
| Temperature Effect On Load | ±0.02%F.S/10℃ |
| Temperature Effect On Zero | ±0.03%F.S/10℃ |
| Construction | Aluminum |
| Protection Class | IP65 |
| Citation | GB/T7551-2008/OIML R60 |
| Mode of Connection | Input+:Red |
| Input-:Black | |
| Output+:Green | |
| Output-:White | |
