Black 230w 16 Channels Moving Head Beam Light With Color Touch Screen

Specifications:

Model Number	MD-A014
Voltage	AC100-240V
Frequency	50-60HZ
Power Consumption	350W
Light Source	OSRAM SIRIUS HRI 280W
Gobo	Two gobo plates, 9 rotating gobos plate+white wheel, 13 fixed gobos+white wheel
Color	13 color+white
Prism	Two prism, 8 prism of round and 6 prism of straight line
Dimmer	0-100% linear dimmer
Strobe	1-13 times/sec, speed can adjust
Control	DMX, master slave, sound active, auto mode
Channel	22CH
Display	LCD display
Pan	540 degree(8/16bit)
Tilt	270 degree(8/16bit)
Focus	0-100% linear(adjust spot/pattern definition)
Zoom	0-100% linear, beam angle 0-20 degrees(adjust the beam/patterm size)
Size	365*256*589mm
Weight	16KG
IP Rating	IP 20
Packing Size	44*41*54CM
Ip Rating	IP20

Technical parameters:

1, Power supply: AC100V - 240 - v
2, Frequency: 50 Hz - 60 Hz
3, Fuse: 7 a
4, Light source: projection lamp/(10R) light bulbs
5, The bulb power: 350W
6, Color temperature: 8500 k
7, Control signal: international standard DMX512
8, Appearance: + high temperature resistant plastic mounding alloy material
9, The light body color: black or white
10, Protection grade: IP20
11, Packing size: 44*41*54CM
12, Weight: 16KG

1, Light bulb not bright:

1.1. Because of abnormal operation, the light bulb not completely cooled, should let the lamp body cooling
more than 10 minutes, make its internal bulb fully returned to normal after restart the power supply.
1.2. Check whether the light bulb to life, should replace new light bulb.
1.3. Check whether bulbs and some bubble line leakage, loss or poor contact.
1.4. Replace the new bubble.

2. Beam look bleak:

2.1. Check whether the light bulb to life, should replace new light bulb.
2.2. Check whether the optical components or the light bulb is clean, the light bulb has dust accumulated on
optical device, such as regular light bulb inside the lamps and lanterns and parts for cleaning and maintenance.

3. The projection image of fuzzy:

3.1. Check whether the electronic focusing channel value is the projection distance right now.

4. The amount of work intermittently:

4.1. Check whether the fan run normally thought is dirty.
4.2. Check whether the internal temperature control switch is in the closed state.
4.3. Check whether the light bulb to life, should replace new light bulb.

5. Although light, but the amount of no longer accept the control of the controller

5.1. Check that the starting address code and check the connection condition of communications lines (1 to 2 +
3)
5.2. Add signal amplifier
5.3. The light bulb in not completely cooled, had abnormal start-up operation, points generated bubble
ultra-high voltage for leaks, and cause circuit board channel chip CPU burn out.

6. The amount can't start:

6.1. Check whether the power input socket on the insurance fusing
6.2. The lamps and lanterns in the long-distance transportation lines caused by the vibration poor contact
6.3. Check the input power, PC board etc. Plug in the device

7. After the self-inspection, some function does not accept the controller control:

7.1. Check this function in the work there is no electricity, or whether this chip by other high-voltage shock
and burn out.

8. X, Y axis electric work in other data recovery a 0, appear abnormal noise

8.1. The abnormal geomagnetic, high voltage leakage lead to burn out the X, Y axis photoelectric sensing
circuit board (light lotus root)
8.2. According to normal procedure to restart the amount
8.3. Push the controller all channel value to 0, the remote reset amount.

Applications:

Applicable for Stage Show, dance halls Disco, nightclubs, KTV, Pub, Bar, television , family party, more
entertainment etc.

Warranty:


If there is the problem with the product, firstly you need send the picture or the video to us, then let us make sure what's problem about the product, we will try our best to help you . If the problem can use the part to solve , we will offer you the replacement for free Within 1 year.
