| Application: | Laser Cutting |
|---|---|
| After-sales Service Provided: | Overseas service center available |
| Certification: | CCC,CE,ISO,FDA |
| Model Number: | rf-1325-co2-150w |
| Brand Name: | rayfine |
| Place of Origin: | China (Mainland) |
| Graphic Format Supported: | AI,BMP,DST,DWG,DXF,DXP,LAS,PLT |
| Control Software: | laserwork |
| Cooling Mode: | Water Cooling |
| CNC or Not: | Yes |
| Cutting Speed: | 0-1000mm/s |
| Cutting Area: | 1300*2500mm |
| Cutting Thickness: | 0-30mm |
| Applicable Material: | Acrylic,Crytal,Glass,Leather,MDF,Metal,Paper,plastic,Plexiglax,Plywood,Rubber,Stone,Wood |
| Laser Type: | CO2 |
| Condition: | New |
| color: | blue white |
| auto feeding device: | optional |
| laser power: | 150w/180w |
| custom made: | yes |
| red dot pointer: | yes |
Quick Details
Specifications
Technical Parameter
| Model | RF-1325-150W-CO2 |
| Up and down size | 250mm |
| Power supply |
AC220±10% 50HZ/AC110±10% 50HZ |
| Working area | 1300*2500mm |
| Laser power | 150w(Option 180w) |
| Max cutting speed | 600mm/s |
| Laser energy control | 1-100% set by software |
| Working table | aluminum knief and honey comb |
| Locating precision |
<0.01mm |
| Max engraving speed | 1000mm/s |
| Operating temperature | 0-45 ℃ |
| Resolution ratio | 1000dpi |
| Control program | laserwork |
| Data transfer interface | USB |
| System environment |
WINDOWS 2000/WINDOWS XP/VISTA/WIN7 |
| Cooling way |
Water cooling and protection system |
| Graphic format supported | BMP,DWG, DXF,DXP,PLT |
| Compatible software | LASER DRAW |
| Cutting thickness |
0-30 mm (depends on different materials) |
| Color separation |
Separation of cutting up to 256 colors |
| Sloping engraving | yes |
| Red dot pointer | yes |
| Packing | plywood case |
| Machine size | 300*170*165cm |
| Net weight | 1000kg |
|
Warranty time |
1 YEAR |
Cutting &Engraving Samples
Buying Guides
*******************************************************************************************************************************
Below information will help us to recommend the most suitable model ASAP.
.What kind of material need to cut?size and max/usual cutting thickness?
.After processed,what is the final product?(application)
.Are you an end user or machine distributor?
*******************************************************************************************************************************
1st: Choose the suitable machine size
We offer various of machine sizes, please choose the suitable working size according to your material size.If you are not very sure, please tell us your material size, we will suggest you the suitable one.
2nd: Choose the suitable laser power
We mainly offer 40W/60W/80W/100W/130W/150W/180W. Smaller power more suitable for engraving, and bigger size mainly for cutting works. Bigger power cut more thickness. Or maybe you can tell us more details about your works, and tell us your cutting thickness. So then can we recommend you the suitable machine model.
**********************************************************************************************************
FAQ
*******************************************************************************************************************************
Q1: How about the delivery time?
A1: For normal machines we can sendout the machine witihn 10 days after receive the deposit.
Q2:How about the delivery term?
A2: We can do FOB ,CIF and DOOR TO DOOR.
Q3:What's the payment term?
A3: We accept: TT,LC,Paypal,Credit card,WU,moneygrame etc.30% deposit is needed for machine production the balance paid before delivery or at sight of copy of BL.
Q4: How about the warranty time?
A4:All parts warranty for one year. For small parts we can send you new one for big value parts we need you send the broken parts back.we recommend you equipe one set of spare parts together with your order which will be more convinient for your work continurous!
Q5: How can i get support from you ?
A5: We supply service through email,tel,online skype etc. We can solve the problem through remote,photos and videos.
*********************************************************************************************************
Our Services
*******************************************************************************************************************************
1.Details English manual book.
2.English documents instruction to show you how to install the machine
according each machine of order(including photos and words).
3.Online remote support appointment: after receive your machine you can
make appoint 24 hours before install the equipment. then our engineer supply
online support when you are ready to start installment.
4. One year warranty: for small parts we can send new as free.if the parts valuable we need you send back the broken one to repair
***************************************************************************************************
