| Item Type: | Flood Lights |
|---|---|
| Light Source: | LED |
| Model Number: | led flood light |
| Brand Name: | led flood light |
| Place of Origin: | China (Mainland) |
| Certification: | CCC,CE,RoHS,UL |
| IP Rating: | IP65 |
| Lamp Body Material: | Aluminum |
| Working Lifetime(Hour): | 50000 |
| Working Temperature(℃): | |
| Beam Angle(°): | 120 |
| Color Temperature(CCT): | Pure White |
| CRI (Ra>): | 85 |
| Lamp Luminous Efficiency(lm/w): | 85 |
| Lamp Luminous Flux(lm): | 1700 |
| Lamp Power(W): | 20 |
| Input Voltage(V): | 80-265 |
| LED Light Source: | 20W high power |
| Power factory: | >0.95 |
| Fixture color: | Silver/Gray/Black |
Quick Details
Specifications
High Power outdoor 10w led flood light
Technical Specifications
|
Item no |
CBY-LF20W-CL1 |
|
led comsuption |
20W |
|
Led chip |
Sanan/Bridgelux / Epistar |
|
Power/Quantity |
1*20W |
|
Luminous |
1700 lm |
|
Power Factor(PF) |
0.95 |
|
Power Efficiency |
> 90% |
|
IP Rating |
IP 65 |
|
Working Life |
50,000 Hrs |
|
Dimension |
180*140*95mm |
|
Color Rendering Index |
Ra> 85 |
|
Housing Color |
Grey, black, White |
|
Shell Material |
Stainless steel & Aluminum |
|
Input Voltage |
AC85-265V /12V -24V DC |
|
Beam Angle |
120 degree |
|
Working Environment |
- 20 - + 50 ° C |
|
Storage Environment |
0 - 50 ° C |
|
Working Humidity |
10 % ~ 90 % RH |
|
System Resistance |
1.4 ° C / W |
|
Color Temperature |
Warm White: 3000-3500K |
|
Nature White: 40,00-4,500K |
|
|
Pure White: 6,000-7,000K |
|
|
|
| Model | Power | Lumen (Lm) | Dimension (mm) |
Warranty |
|---|---|---|---|---|
|
CBY-FL-10W-CL1 |
10W |
850 |
115*86*85 |
3 years |
|
CBY-FL-20W-CL1 |
20W |
1700 |
180*140*95 |
3 years |
|
CBY-FL-30W-CL1 |
30W |
2550 |
225*185*120 |
3 years |
|
CBY-FL-50W-CL1 |
50W |
4250 |
290*240*140 |
3 years |
|
CBY-FL-70W-CL1 |
70W |
5950 |
370*290*80 |
3 years |
|
CBY-FL-80W-CL1 |
80W |
6800 |
370*290*80 |
3 years |
|
CBY-FL-100W-CL1 |
2x50W |
8500 |
370*290*85 |
3 years |
|
CBY-FL-120W-CL1 |
2x60W |
10200 |
425*325*190 |
3 years |
|
CBY-FL-150W-CL1 |
3x50W |
12750 |
425*325*190 |
3 years |
|
CBY-FL-180W-CL1 |
3x60W |
15300 |
425*325*190 |
3 years |
|
CBY-FL-200W-CL1 |
4x50W |
17000 |
525*325*190 |
3 years |
|
CBY-FL-240W-CL1 |
4x60W |
20400 |
525*325*190 |
3 years |
Applications:
1-Replacement for conventional Haligan lamps
2-super markets
3-Factories and offices
4-Commercial complexes
5-squareys
6-Government projects, Railway Stations, Airports, Schools
