Specifications
|
|
Model No.
|
TM-PJ4603
|
|
Screen size
|
46'' Samsung DID LCD screen(super narrow bezel 7.3mm)
|
|
Aspect Ratio
|
16:9
|
|
Resolution
|
1366x768
|
|
Color
|
8Bit, 16.7M
|
|
Brightness (nits)
|
450cd/m2
|
|
Contrast
|
2000:1
|
|
Visual angle (H/V)
|
178°
|
|
Response time
|
< =6ms
|
|
Life(hrs)
|
> 60,000(hrs)
|
|
Input and output
|
|
Composite Video Input
|
3(3xBNC)
|
|
YUV/YPbPR
|
1(3xBNC)
|
|
S-YC
|
1(2xBNC)
|
|
D-15 RGB Input(VGA)
|
1
|
|
HDMI
|
1
|
|
DVI
|
1
|
|
Audio Input
|
1
|
|
Composite Video Output
|
2(2xBNC)
|
|
Split Screen
|
Support Picture in Picture(PIP/POP/PAP)
|
|
Power
|
|
Power supply
|
AC100V~240V
|
|
Maximum power consumption
|
250W
|
|
Standby power consumption
|
< =3W
|
|
Temperature
|
|
Working temperature
|
0°C~50°C
|
|
Working humidity
|
20%-80%
|
|
Appearance
|
|
Product dimension( W x H x D) mm
|
1025.65x579.84x126.73
|
|
Acessory
|
|
Cable
|
Can supply different kinds of cable
|
|
Video Wall Controller(Built-in each screen)
|
|
Model No.
|
TM-P816A
|
|
Input
|
CVBS
|
3*BNC inputs, support PAL/NTSC all formats, 2*BNC loop outputs
|
|
VGA
|
1*D15 port, support SVGA/XGA/WXGA
|
|
YPbPr/YCbCr
|
1* YPbPr/YCbCr input, support PAL/NTSC all formats, and 720P, 1080I, HDTV
|
|
Y/C
|
2*BNC inputs, support PAL/NTSC all formats
|
|
Output
|
LVDS
|
Support signal or double LVDS output, and WUXGA (1920*1080) display
|
|
Operate mode
|
Panel key operation(needs customization)
|
|
Standard RS232 port( provide free control software)
|
|
Infrared Remote Control Operation
|
|
Engineering software
|
Customized
|
|
Working temperature
|
0~70 °C
|
|
working humidity
|
5~95 %RH
|
|
AC voltage power supply
|
100-240V/50, 60Hz
|
|
power consumption
|
Max 300W, according to different screen models
|
|
Dimension
|
338×295×60(mm)
|
|
Weight
|
About 3.5KG
|
