| Input Voltage: | 110-220V |
|---|---|
| Response Time: | 8S |
| Brightness: | 450 |
| Contrast Ratio: | 3000:01 |
| Color: | Fully color |
| Viewing Angle: | 178 |
| Max Resolution: | 1920*1080P |
| Panel Size: | 42 |
| Application: | Indoor |
| Type: | TFT |
| Model Number: | TM02P42LD01 |
| Brand Name: | Tonme |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Stand alone indoor wireless wifi indoor tv screen panel lcd wall mounting ad play with media screen
Our advantage
1.We promise 100% full new brand A+ LCD panel, generally speaking adopt LG, Samsung,it owns long use life and good visual effect. 2. We have English after-sale service engineers provide after sales service by English directly, all the problems can be solved in time. 3. We have our own outer shell&enclosure factory to accept OEM&ODM design order, quite experienced in customized item for client
|
Display |
|
|
Type of Display |
Commercial LCD(Samsung or LG) |
|
Panel Size |
42 inch indoor tv screen panel lcd wall mounting ad play with media screen |
|
Display Ratio |
16:9 |
|
Resolution (pixel) |
1920x1080 |
|
Color |
16.7M |
|
Pixel Pitch (mm) |
0.2835(H)×0.2835(V) |
|
Brightness(nits) |
500cd/m2 |
|
Contrast |
5000:1 |
|
View Angle |
178o |
|
Response Time |
8ms |
|
Life (hrs) |
50000 hours |
|
Touch Screen |
|
|
Screen Size |
42 inch |
|
Resolution (pixel) |
1920x1080 |
|
Detection Method |
Infrared touch(2 points) |
|
Casing material |
tempered glass & aluminium |
|
Touch material |
finger, touch pen, etc |
|
Touch lifetime |
single touch 60 million |
|
Luminousness |
97% -99% |
|
Precision |
<2mm |
|
Chemical resistant |
Mohs\ hardness rating of 7 |
|
Android player(optional PC player) |
|
|
CPU |
A20 , dual core 1.0 GHz |
|
Memory |
8G(optional) |
|
Internal storage |
NAND FLASH 4G(optional) |
|
Decoding resolution |
Max support 1080P |
|
Operating system |
Android 4.2.2 |
|
Play mode |
To support recycling, timing and other display modes |
|
Network |
3G, Ethernet, support WiFi |
|
Video Player |
Support wmv, avi, flv, rm, rmvb, mpg, ts, mp4, mkv, etc |
|
Picture format |
Support BMP,JPEG,PNG,GIF |
|
USB2.0 port |
One USB HOST, two USB socket |
|
RS232 port |
Two RS232 socket |
|
Ethernet |
One 10M/100M Adaptive Ethernet |
|
SD card interface |
Can insert SD or TF card |
|
SATA interface |
Support Built-in SATA hard disk |
|
LVDS output |
One,Can directly drive 50/60Hz LCD screen |
|
HDMI output |
One, support 1080P |
|
Audio and video output |
Support CVBS vedio output,left and rightsound channel output, Built-in two 6W amplifier |
|
RTC real-time clock |
Support |
|
Stereo Speakers |
Inclusive two |
|
Body |
|
|
Cabinet |
Galvanized steel sheet. Thickness:1.0-1.5mm. Aluminum profiles extruded for both sides. |
|
Color |
black , white , silver or customized colors |
|
Packing |
One carton package one Kiosk |
