| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | 1 year |
| Certification: | CE |
| Weight: | 440kgs |
| Dimension(L*W*H): | 157*122*167cm |
| Power(W): | 1.5kw |
| Voltage: | 220/380v |
| Model Number: | NC-B6090 |
| Brand Name: | NICECUT |
| Place of Origin: | China (Mainland) |
| CNC or Not: | CNC |
| Condition: | New |
| Application: | Desktop cnc router |
| Spindle power: | 1.5kw |
| X,Y,Z transmission: | Ball screw |
| Spindle speed: | 0-18000RPM |
| Working mode: | Stepper motor |
| Control system: | NC-Studio or DSP |
| Software: | Type3 and Artcam |
| Color: | Optional |
| Delivery time: | 7-10 working days |
| Packing: | Wooden case |
Quick Details
Specifications
Nice-Cut NC-B6090 cnc router machine/wood cnc router/ desktop cnc router
Property features:
1. High speed process: can process curves and straight lines simultaneously at the speed of 6m/min;
2. Massive memory capacity:standard allocation of 128M can save over 20 files simultaneously for your choies;
3. Quick data transmission: adopt advanced USB interface,working without computer,not acuupy any resources;
4. Convenient operation: owing the function of restoring from power-off,continuation on break point,anticipate working time,
auto-feeding blades,user-friendly designing.
Samples display:
Parameters:
|
Discription |
Parameter |
|
|
1 |
X,Y,Z Working Area |
600x900x120mm |
|
2 |
Table Size |
720X1135mm |
|
3 |
X,Y,Z Traveling Positioning Accuracy |
±0.03/300mm |
|
4 |
X,Y,Z repositioning Positioning Accuracy |
±0.05mm |
|
5 |
Lathe Structure |
Cast Aluminum |
|
6 |
X, Y Structure |
Shaft Linear Bearings and Ball Screw |
|
7 |
Z Structure |
Ball Screw |
|
8 |
Max.Consume power |
3.0Kw |
|
9 |
Max.Speed |
0-6000mm/min |
|
10 |
Max.Working Speed |
0-3000mm/min |
|
11 |
Spindle Power Motor |
1.5Kw Chinese (1.5Kw HSD spindle) |
|
12 |
Spindle Speed |
0-18000RPM |
|
13 |
Working Mode |
Stepper |
|
14 |
Working Voltage |
AC220V/50/60Hz |
|
15 |
Command |
G code, *uoo, *mmg, *plt |
|
16 |
Operating System |
DSP System |
|
17 |
Interface |
USB |
|
18 |
Flash Memory |
128M |
|
19 |
Collet |
ER18 |
|
20 |
X,Y Working Delicacy |
<0.01mm |
|
21 |
Software |
Type3 software, Wentai software, Artcam software |
|
22 |
Running circumstance |
Temperature: 0°C~45°C |
|
23 |
Packing Size |
1710X1200X1495mm |
|
24 |
Net Weight |
190KG |
|
25 |
Gross Weight |
252KG |
|
All parameters above subject to change without prior notice |
||
