| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | 1 year |
| Certification: | CE |
| Weight: | 650kgs |
| Dimension(L*W*H): | 305*195*189cm |
| Power(W): | 1.5kw |
| Voltage: | 220/380v |
| Model Number: | NC-B1212 |
| Brand Name: | NICECUT |
| Place of Origin: | China (Mainland) |
| CNC or Not: | CNC |
| Condition: | New |
| Application: | Wood cnc router machine |
| Spindle power: | 1.5kw |
| Working area: | 1200*1200*120mm |
| Driving system: | Stepper motor |
| Control system: | DSP |
| Lathe Structure: | Cast steel |
| X,Y transmission: | Ball screw and square guide rail |
| Z transmission: | Ball screw |
| Packing: | Wooden case |
| Delivery time: | 7-10 working days |
Quick Details
Specifications
NC-B1212 advertising cnc router/wood engraving cnc router machine
Features:
Features:
1. Solid gantry, good structure of lathe bed, stable lathe table, fast speed and high accuracy .
2. High-speed water cooling spindle and high performance subdivision driver ensure to work stably for a long time.
3. NC-R1212 wood CNC router adopts the advanced CNC system (NC studio or DSP control system), This system has broken point memory mode and special saving made of different points so that it can make sure continuous working after electronic drop or other postponed situation. This function can guarantee the processing precision of long time operation. Practical configuration and easily-learned software, conveniently check the moving path of tool, and adjust the processing depth of Z axis and the speed of motor.
4. NC-B1212 wood CNC router is widely used in woodworking, carving, cutting, engraving, and the work materials are wood, MDF, aluminum panels, ABS, acrylic, PVC, a variety of decorative materials.
In order to better serve the customs, we also offer other kinds of CNC routers and laser machines, such as mini CNC routers, woodworking CNC routers, multiheads CNC router, 3D CNC router, woodworking machine center, ATC CNC router and etc. If you are interested in our advertising CNC router, please feel free to contact us.
Samples:
Specification:
| Name | Specification |
|---|---|
| X-Y-Z Working Area | 1220x1220x120mm |
| Table Size | 1340X1545mm |
| X-Y-Z Traveling Positioning Accuracy | ±0.03/300mm |
| X-Y-Z repositioning Positioning Accuracy | ±0.04mm |
| Lathe Structure | Cast Steel |
| X, Y Structure | Ball Screw, Shaft Linear Bearings / Square Rail, Gear Rack |
| Z Structure | Ball Screw, Shaft Linear Bearings, Square Rail |
| Max. Consume Power | 3.5Kw |
| Max. Speed | 0-6000mm/min |
| Max. Working Speed | 0-3000mm/min |
| Spindle Power Motor | 1.5kw water-coolant spindle |
| Spindle Speed | 0-24000RPM |
| Drive Mode | Stepper Motor |
| Working Voltage | AC220V/50/60Hz |
| Command | G Code, *uoo, *mmg, *plt |
| Operating System | DSP System |
| Interface | USB |
| Flash Memory | 128M |
| Collet | ER18 |
| X-Y-Z Working Delicacy | < 0.01mm |
| Software | Type3, Ucancam, Artcam |
| Running circumstance | Temperature: 0°C~45°C Relative humidity: 30%~75% |
| Packing Size | 1800x1830x1450mm |
| Net Weight | 400KG |
| Gross Weight | 450KG |
| All parameters above subject to change without prior notice | |
