| Brand Name: | VG |
|---|---|
| Temperature of Media: | Medium Temperature |
| Material: | CAST IRON |
| Pressure: | Medium Pressure |
| Standard or Nonstandard: | Standard |
| Model Number: | F7359 |
| Place of Origin: | China (Mainland) |
| Port Size: | 50-250 |
| Media: | Water |
| Power: | Manual |
| Structure: | Check |
Quick Details
Specifications
Description;
1)F7359-Marine cast Iron 5K lift Check Angle valve
Nominal pressure; 5K(0.49Mpa)
DN50, 65, 80, 100, 125, 150, 200, 250
1.End Type; Flange
2. Lift Angle Type
3. Main material;
Body/Bonnet;FC200;
Disc/Valve seat; BC6; or brass or Stainless Steel 2CR13 or 1CR13
Gasket; Non-asbestos;
4.Application;Sea water piping, fresh water piping, oil piping and steam piping.
5.Function:the products are used for preventing refluence in fuel oil, lubricating oil, and water piping at or under the temperature of 120 degree.Jis valve manufacturer in Qingdao China
Jis marine valve 5k 10k 16k 20k 30k 40k
Jis marine cast iron valve
Jis marine cast steel valve
Jis marine bronze valve
Jis marine globe valve
Jis marine gate valve
Jis marine swing/lift/sdnr check valve
Jis marine hose valve
Jis marine storm valve
Jis marine air vent head
Jis marine strainer
Self closing drain valve jis F7398
Emergency shut off valve JIS F7399
