Description of gold silver copper melting machine:
1. High efficiency of melting, power saving, compact structure, high overload capacity.
2. The operating situation around furnace is low temperature, few smoke dust and comfortable.
3. Easy operation process, reliable smelting running.
4. Metal composition is evenly distributed.
5. Fast heating rate, furnace's temperature is easy to control, high production efficiency.
6. The usage of furnace is widely. And it is convenience to change materials.

Applications of gold silver copper melting machine:
1. melting precious metal such as gold, silver, copper and other metals.
2. gear shafts heat treatment, surface quenching
3. hot forging of bolts nuts ,steel rods, square steel, and steel billet etc. for bending and forming
4. induction brazing welding of carbide cutters, hard alloy, gun drill, copper pipes, drill bits etc.
5. Shrink fitting, remove inserts from hemisphere billet etc.
6. Steel billet hot forge, bending ,forming
7. Angle iron heating for forging
8. Camshaft hardening

Our service for gold silver copper melting machine:
1.We will do the long term tech supporting for your specific solution.
2.We have 24 hours online service for you from all over the world.
3.We will design you the best solution for your requires, smart choosing of models and power, induction coil and other configurations.
4.1 year warranty for free and on site install and training.

Parameters of gold silver copper melting machine:

type	WH-VI-50	Working Power	380v/50-60hz
Melting Capacity of Gold	20kg	Working Voltage Range	342A-430A
Melting Capacity of Aluminum	6kg	Cooling Water Pressure	0.1-0.3mpa
Melting Capacity of Steel	5kg	Efficiency	100%
Max Output Power	50kw	Colour	Blue/White
Max Input Current	75A	Continuous Load Rate	100%
Size of Transformer	420*355*450mm	Size of Host	590*450*780mm
max heating temperature	1800 degree	Host weight	55kg±5%kg
Transformer Weight	35kg±5%kg	Temperature Protection	50 Degree
