| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Certification: | CE |
| Weight: | 100-500kg |
| Brand Name: | Acore |
| Condition: | New |
| Dimension(L*W*H): | option |
| Power(W): | 30-150kw |
| Voltage: | option |
| Usage: | Lubricant Oil |
| Model Number: | PF |
| Place of Origin: | China (Mainland) |
| Working Pressure: | 0.4Mpa |
| Flow: | 10-300L/min |
| Type: | high precise filters |
Quick Details
Specifications
Application:
Is
Also ideal unit for pre-filter and transfer fluids to reservoirs, tank or clean
up existing system, it can help users maintain fluid cleanliness, improve
Performance, and reduce their amount of waste and disposal costs
Range of industrial fluids applications includes
? Hydraulic oil
? Lubricating oil
? Turbine oil
? Compressor oil
? Gear oil
? Insulating oil
? Engine oil
? Water-glycol fluid
? Ester base fluid
? Fuels
? Engine Oil
Technical specification
Model |
PT-20 |
PT-30 |
PT-50 |
PT-80 |
PT-100 |
PT-125 |
PT-150 |
PT-200 |
PT-300 | ||
Capacity(L/min) |
20 |
30 |
50 |
80 |
100 |
125 |
150 |
200 |
300 | ||
Work pressure |
≤0.4 (Mpa) | ||||||||||
Filter precision |
≤1Micron | ||||||||||
Cleanness |
≤6 degree (NAS 1638) | ||||||||||
Motor |
Power (KW) |
0.75 |
1.2 |
1.5 |
2.2 |
2.5 |
3 | ||||
Speed(r/min) |
910 |
930 |
950 |
960 |
980 |
1000 | |||||
Power supply |
380V,50HZ,3Ph ( orCustomized) | ||||||||||
Head (m) |
≥15 | ||||||||||
Inlet/outlet(mm) |
20 |
25 |
32 |
38 |
44 |
48 |
50 |
58 |
65 | ||
Dimension (mm) |
L |
600 |
800 |
800 |
800 |
800 |
810 |
950 |
950 |
1000 | |
W |
600 |
750 |
760 |
800 |
800 |
800 |
800 |
810 |
850 | ||
H |
900 |
950 |
980 |
1000 |
1000 |
1000 |
1000 |
1100 |
1150 | ||
Weight (kg) |
100 |
130 |
160 |
195 |
220 |
240 |
250 |
300 |
330 | ||
