| Type: | Labeling Machine |
|---|---|
| Automatic Grade: | Automatic |
| Packaging Material: | Glass,Plastic |
| Packaging Type: | Bottles |
| Application: | Beverage,Chemical,Commodity,Food,Medical |
| Condition: | New |
| After-sales Service Provided: | No overseas service provided |
| Dimension(L*W*H): | (L)1120mm (W)728mm (H)1130mm |
| Model Number: | LR-460 |
| Brand Name: | AutoPack |
| Place of Origin: | Taiwan |
| Power: | single phase 110/220VAC, 50/60Hz |
Quick Details
Specifications
- Customized Industry Plastic Roller Conveyor for accurate placement
- Encoder Synchronizes Horizontal Wrap Station with Applicator
- Height and angle are adjustable
- Controlled by Microprocessor, LED display
- Label Count Down feature/ Production Run Counter
- Sick Sensation System for Label Gap Detection
- One Touch label set and potitioning
- Modular design for easy maintenance/ quick and easy changeover
- Sanitary SUS#304 and anodized aluminum frame
OPTIONS:
- Hot Stamping Coding Machine(PE-200, PM-200)/ Ink jet printer
- Custom Loading Case to be desinged each product size
- LION LDR2100 Clear Label Sensor
- Mitsubishi Servo Motor: Labeling Speed at 40 Meter/Min
- Touch Screen Control System with Job Memory
- Stainless Cabinet Type
- Standard Infeed & Accumulation Tray
- Motorized Infeed and Accumulation Rotary Table (600mm or bigger)
- Belt Type Infeed system: Larger Capacity
- Stepper Motor Drivens
- Labeling Speed: 80~150 pcs/min(Depends on Container and Label Size)
- Bottle Size: Diameter 9.5~25 mm / Height 30~160mm
- Label Width: 10~100mm/Label Length: 20~300mm
- Label Roll: Inner diameter 75mm / Outer Diameter 300mm
- Power: single phase 110/220VAC, 50/60Hz
- Machine Dimensions: (L)1120mm (W)728mm (H)1130mm
