| Brand Name: | Thermal |
|---|---|
| Model Number: | TMH-16-2 |
| Place of Origin: | China (Mainland) |
| Voltage: | 110 |
| Power: | 1200 |
| Feature: | 360 Degree Rotational Base |
| Material: | Copper |
| Certification: | CE,RoHS,UL |
| Length: | 10mm-6000mm |
| Tube diameter: | 6-20MM |
| Surface treatment: | scale-proof or corrosion-proof |
| Power: | 200W-5000W(Customized) |
| Voltage: | 12V-380V(Customized) |
| Material: | Copper,SS304,316 ,Tianium etc |
| Type: | Oven Heating Element |
Quick Details
Specifications
Iron Heating Element for Sandwich Maker/Oven
-
Specification 1.Oven heating element. 2.Voltage & Power: 110V-240V,200W-10000W 3.Available materials include SUS304,SUS316,SUS321 Incoloy840,Incoloy800. 4.Pipe diameter are 6.6mm, 8.0mm and 10.0mm. Size is non-standard and customized. 5.The surface load of the heating pipe is 9.8W/cm2. -
Description for electric heating element:
- Type electric heating element for kettle
- Usage die-casting/staking and others
- Material: Incoloy800/840;SUS321/316/304/, aluminum, Copper and more
- Temperature 800°C maximum
- Sealing silicone oil, precoated MgO,RTV
- Sheath diameter 6.30, 6.60, 8.00, 10.00mm
- Power: 110-400V/ up to 10KW
- Certificate: CE/VDE/REACH/RoHS approval
- Surface: without/with black or green treatment
- Special design per your request
- Rapid response time of control system & compact design
- Main technical information:
- Cold state insulation resistance: > 50MΩ
- Grounding resistance: <10Ω
- Surface temperature can reach 800 without burning phenomenon
- Use condition: Environmental temperatures: -20 ~ 60
- Can be made according to your requirements of various style
