| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | 12 months |
| Certification: | CE |
| Weight: | 1300kg |
| Dimension(L*W*H): | 3.1*2.2*1.7m |
| Power(W): | 4.5kw |
| Voltage: | 220v/380v |
| Model Number: | DL1325 |
| Brand Name: | DLTECH |
| Place of Origin: | China (Mainland) |
| CNC or Not: | CNC |
| Condition: | New |
| rails: | XYZ linear square rails |
| transimission: | XY rack and pinion drive,Z axis ball screw drive |
| oiling system: | hand oiler |
| control system: | mach3 with handwheel |
| z axis clearance: | 300mm |
| machine table: | vacuum with T-slot combined |
| machine bed: | heavy duty |
| color: | optional |
| voltage: | 220v/380v |
| payment: | TT,paypal,westerunion |
Quick Details
Specifications
1) Machine bed is stress released for 25 days to make sure the high precision.
2)Adopt YAKO motor and driver,high speed and more stable.
3) Heavy duty machine bed,not easy to be out of shape.
4) be tested for 75 hours in Continuous work
|
Model |
QC1325 |
|
Working area |
1300*2500*300mm |
|
spindle |
3.0 kw (for two sets),4.5kw(for one set)water cooled spindle |
|
Limit switch |
Yes |
|
Invert |
Fuling invert |
|
Control system |
Mach3,4 aixs card with handwheel |
|
XY axis |
Imported Taiwan HIWIN helical rack and pinion |
|
Z axis |
Ball screw drive |
|
Drive motor |
YK86HB118-06A |
|
Driver |
YAKO2811MA |
|
Working table |
Vacuum table and T-slot combined |
|
Driving model |
XY rack and pinion drive,Z ball screw drive |
|
Vacuum pump |
Two sets 2.2kw air pump |
|
Hand oiler |
Yes |
|
Max cutting speed |
20m/min |
|
Max engraving speed |
35m/min |
|
Voltage |
AC220V/50Hz,single phase |
|
Machine body |
Heavy duty machine bed (three legs design) |
|
Package dimension |
3.89*2.26*1.51m |
|
Net weight/Gross weight |
1300kg/1500kg |
