| Processing: | Emulsifier |
|---|---|
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Processing: | dispersing |
| Weight: | ~6kg |
| Brand Name: | FLUKO |
| Condition: | New |
| Warranty: | 1 year |
| Certification: | ISO9001 |
| Power(W): | 500W |
| Voltage: | 220V,50HZ |
| Model Number: | F22Z |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Features&Performance
1.Efficient dispersing and homogenizing without no dead corner;
2.High power motor originally imported from Germany;
3.Special designed stator/rotor generates Super high shear force;
4.Can simulate inline or batch circulation Processes;
5.Optional stainless steel and glass Jacket working chamber.
Technical Specifications
Motor power |
F22Z |
Power supply |
220V,50HZ |
Flow rate range(H2O) |
1-15L/min |
Maximum working viscosity |
1000CP |
Speed range |
10000-28000rpm |
Temperature |
120℃ |
Speed display |
Scale display |
Speed control |
Stepless |
Medium-contact material |
SS316L,FKM |
Standard working chamber |
Stainless steel chamber without jacket |
Standard dispersing agitator |
20DG |
Mechanical seal material |
Sic, FKM |
Inlet/outlet size |
14(Hose connection) |
Process type |
Inline processing |
Working base material |
SS304 |
Overall dimensions |
362*120*112 |
Weight |
6kg |
