| Processing: | Emulsifier |
|---|---|
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Processing: | dispersing |
| Weight: | ~12kg |
| Brand Name: | FLUKO |
| Condition: | New |
| Warranty: | 1 year |
| Certification: | ISO9001 |
| Voltage: | 220V,50HZ/60HZ |
| Processing Types: | |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Features&Performance
1.Efficient dispersing and homogenizing without no dead corner;
2.High power motor originally imported from Germany;
3.Special designed stator/rotor generates Super high shear force;
4.Can simulate inline or batch circulation Processes;
5.Optional stainless steel and glass Jacket working chamber.
Technical Specifications
Motor power |
1800W |
Power supply |
220V,50HZ/60HZ |
Flow rate range(H2O) |
1-30L/min |
Maximum working viscosity |
1000CP |
Speed range |
2500-23500rpm |
Temperature |
120℃ |
Speed display |
Scale display |
Speed control |
Stepless |
Medium-contact material |
SS316L,FKM |
Standard working chamber |
Stainless steel chamber without jacket |
Standard dispersing agitator |
40DG |
Mechanical seal material |
Sic, FKM |
Inlet/outlet size |
18(Clamp connection) |
Process type |
Inline processing |
Working base material |
SS304 |
Overall dimensions |
515*180*150 |
Weight |
~12kg |
