| Contact |
Contact Form |
1A,1C |
| Rated Load |
Resistive |
6A/250VAC 30VDC |
| Motor |
|
| Operating Power(Resistive) |
1500VA 180W |
| Contact Resistnce(Initial) |
≤100mΩ (gold plated contact ≤30mΩ ) |
| Material |
Ag alloy |
| Electrical Life |
≥60,000 cycles (1800 Ops/h) |
| Mechanical life |
≥ 10,000,000 cycles (18000 Ops/h) |
| Operate Voltage( at 23°c) |
DC:≤75% rated voltage |
| Release Voltage ( at 23°c) |
DC:≥5% rated voltage |
| Max. Allowed Voltage ( at 23°c) |
110% rated voltage |
| Insulation resistance |
≥500 MΩ (500VDC) |
| Coil Power Consumption |
3~24VDC(W) |
0.17 |
| 48~60VDC(W) |
0.21 |
| Operate Time |
≤8ms |
| Release Time |
≤4ms |
| Dielectric Strength |
between Contacts |
1000VAC/1 min (Leakage current 1 mA) |
| between Contact and Coil |
4000VAC/1 min (Leakage current 1 mA) |
| Ambient Temperature |
-40~+85°c |
| Humidity |
35%~85% RH |
| Atmospheric Pressure |
86-106 KPa |
| Shock Resistance |
10G |
| Vibration resistance |
10~55Hz Dual Amplitude:1.0mm |
| Install Model |
PCB terminal |
| Weight |
6 g |
