| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Certification: | SGS |
| Weight: | 45t |
| Dimension(L*W*H): | 3800*2400*2600 |
| Power(W): | 132kw |
| Voltage: | 110L |
| Model Number: | M110/JDL150 |
| Brand Name: | JDL |
| Place of Origin: | China (Mainland) |
| Automatic Grade: | 1 |
| Screw Design: | Single-screw |
| Plastic Processed: | Polystyrene |
| Application: | Sheet |
| Condition: | New |
Quick Details
Specifications
Adopt ZLYJ series professional for single screw rubber/plastic matched designed,
high precise hard gear transimit case with thrust block
Invert motor or invert adopt level2 environmental standard
The screw adopt separate structure
Hopper:material is 38CrMoALA nitriding process,nitrigon HRC65-70.depth0.6-0.75mm,brightness is more than level II
Soft water circle cooling system and vacuum :soft water pipe and machine body is separate,easy for clean and maintain,adopt pressure hopper connect
Heat section:import omron dual channel temperature cotroller;high precise solid state relay;use high quality cast aluminum heater.
Hydraulic plate automatic change net
Sheet mold :type hanger die with double throttling design,make the plate thickness is more accurate,Temperature can be precise plasticizing process and plate thickness.Discharging effective width 2150mm;products width 2100mm;thickness 3-8mm,
Die material:5CrNiMoVsteel,a total of 11 district heating,adopt stainless steel heating bar,die head stream surface hard chromium plating processing.
