Sewing speed: 3000rmp ( stitch 5.0mm, Y 3.5 mm following)

Stitch length: 0.1~10.0mm  (0.1 unit)

Pressure foot Feeding: Intermittent feeding (pulse motor double shaft drive mode)


Needle bar stroke: 41.2MM

Needle: DP×5  Dp×17

Pressure foot lift up amount  Standard 13mm Highest 17mm

Hook: Screw to fix Hook (add oil)

Oil: No.2 New machine (oil filling way)

Data record: EE-PROM  (128K byte) E-PROM  (32K byte)

Direct to the right and reduce the function   X direction, Y to the direction of 20~200% (1% for unit)

Enlarge,reduction mode: Stitch length change mode

Stitching speed length mode: 400~3000rmp (100rmp unit)

Pattern selection function: Pattern No. Specify mode (1~200)

Bobbin thread counter: up/down mode (0~9999)

Motor: Direct drive servo motor

Measurement: W:1200MM L:660MM H:1100MM (Standard stand)

Weight: Machine head 42 kg, CPU 16.5kg

Power consumption: 320W

Temperature range: 5℃~35℃

Humidity range: 35%~85% ( condensation of moisture)

Power: Voltage 10% 50Hz/60Hz
