| Brand Name: | AFT |
|---|---|
| Accuracy: | 1.0% |
| Power Supply: | 12-24VDC, 3.6V |
| output: | 4-20mA;RS485 |
| Medium: | Gas / Non-conductive liquid |
| Model Number: | LUGB |
| Place of Origin: | China (Mainland) |
| Product name: | 4-20mA Local DisplayVortex Gas Flow Meter |
| Pressure: | 1.6mPA, 2.5Mpa, 4.0Mpa |
| Protection Grade: | IP65 |
| Material: | Stainless Steel |
| Display: | LCD Digital |
| Connection: | Flange: DN20-DN1000 |
Quick Details
Specifications
4-20mA Local Display Vortex Gas Flow Meter
4-20mA Local Display Vortex Gas Flow Meter Features:
1. Simple structure, no moving parts wear;
2. High accuracy and good reliability, don't need on-site debugging;
3. Can be long-distance transmission of flow signals, and computer networking, centralized management;
4. Unique design of the amplification board, gas or liquid can be used.
Product Description
Technical Parameters
|
Measured Medium
|
Liquid, Gas, Steam
|
|
|
Medium Temp. |
-40~+200;-40~+280;40~+350
|
|
|
Nominal Pressure |
1.6MPa;2.5MPa;4.0MPa;64MPa(Other pressure can be custom)
|
|
|
Accuracy |
1.0%,1.5%
|
|
|
Measuring range ratio |
1:8-1:30(Standard air condition as reference), 1:8-1:40(Normal Temperature as reference)
|
|
|
Flow range |
Liquid:0.4-7.0m/s; Gas:4.0-60.0m/s; Steam:5.0-70.0m/s
|
|
|
Specifications |
DN15~DN600 |
|
|
Material |
1Cr18Ni9Ti
|
|
|
Reynolds number |
Normal 2*104~7*106
|
|
|
Resistance coefficient |
Cd2.6
|
|
|
Vibration acceleration Allowed
|
LUGB0.2g
|
|
|
Ex-proof class |
IP65 ExiaIICT6 Ga |
|
|
Ambient condition |
Ambient Temp. |
-40-65(Non Display on site); -20-55(Display on site |
|
Relative humidity |
5%~93% |
|
|
Pressure |
86-106kPa |
|
|
Power Supply |
12-24V/DC or 3.6V battery powered
|
|
|
Signal Output
|
Pulse frequency signal2-3000Hz,Low level1V,high level6V
|
|
|
Two-wire system 4-20 signal(isolated output),Load500 |
||
