DESCRIPTION

Hiperco 50A © is an iron-cobalt-vanadium soft magnetic alloy which exhibits high magnetic saturation , high d.c. maximum permeability, low d.c. coercive force, and low a.c. core loss.

 APPLICATION

Special Motors for the Aerospace Industry.Electromagnets for medical applications ,Electrical Generators; Specialty Transformers,Pole Pieces for Electromagnets; Magnetic Bearings ,High Magnetic Flux Devices and Instruments.

 CROSS REFERENCE

GRADE	USA	RUSSIA	UK	STANDARD
HIPERCO50	SUPERMENDUR	50Φ	PERMENDUR	gB/t15002-1994

Typical Chemistry

C	MN	SI	P	S	CU	NI	V	CO	FE
0.04	0.30	0.30	0.020	0.020	0.20	0.5	0.8-1.8	49.0-51.0	BALANCE

PHYSICAL PROPERTY

PROPERTY	METRIC	IMPERIAL
DENSITY	8.20 g/cm3	0.295lb/in3
ELECTRICAL RESISTIVITY	253/ohms/mf	420/Microhm-mm

 MECHANICAL PROPERTIES

Properties	Metric	Imperial
Tensile strength	1345MPa	195100pSI
Yield strength (@ strain 0.200%)	1275MPa	184900Psi
Hardness, Brinell (estimated from Rockwell C for 3000 kg load, 10 mm ball Brinell measurement)	334	334

SIZE RANGE

SHEET	Thickness:0.10mm~0.50mm, width:10.0~210mm
PLATE	Thickness:3.5mm~4.0mm, width: ≤300mm
ROD	Dia 8.0mm~Dia 32.0.0mm, length≤2000
	Dia 32.0mm~Dia 150.0.0mm, length≤1000

Condition: cold rolled, hot rolled ,bright, burnished, hot forging ,peeled, turned



Remarks:                                          Heat Treatment

 When selecting a heat treating temperature for the application, two factors should be considered:

1. For best magnetic soft characteristics, select the highest suggested temperature.

2. If the application requires specific mechanical properties higher than that produced when employing

the  highest temperature, select the temperature that will provide desired mechanical properties.





As temperature decreases, magnetic properties become less magnetic soft. Heat treating temperature for best soft magnetic properties should be 1625°F +/- 25°F (885°C +/- 15°C).Do not exceed 1652°F(900°C).



The heat treating atmosphere used must be nonoxiding and noncarburizing. Atmospheres such as dry hydrogen or high vacuum are suggested. Time at temperature should be two to four hours. Cool at a rate of nominally 180 to 360°F (100 to 200°C) per hour to a temperature of least 700°F(370°C), then cool naturally to room temperature
