Material: | steel |
---|---|
Size: | 3/8''~4'' |
Protection Level: | IP67 |
Brand Name: | driflex |
Color: | silver |
Place of Origin: | China (Mainland) |
Quick Details
Specifications
Features:
Galvanized steel, square-locked core with cord packing from 3/8" to 1-1/4", interlocked core from 1-1/2" to 4" to give additional strengh to prevent unravelling
Smooth wipe clean PVC jacketed
Liquid-tight IP66/IP67
Good flexibility
High mechanical strength
Flame retardent
UV protection
Moisture proof
Resistance to most of chemicals, such as oil, acids and vapours, etc.
Good Absorption of motion and vibration
Special Applications:
According to customer's samples and specifications, we can manufacture special fittings for suit any type of flexible conduit applications.
Specifications:
Part No | ISO Thread (mm) | Part No | NPT Thread (inches) | I.D. (mm) | O.D (mm) | Box (pcs) |
---|---|---|---|---|---|---|
LTCM-09 | 16 | LTC-09 | 5/16" | 11.0 | 15.7 | 25 |
LTCM-10 | 16/20 | LTC-10 | 3/8" | 11.0 | 19.7 | 25 |
LTCM-11 | 20 | LTC-11 | 1/2" | 14.5 | 19.7 | 25 |
LTCM-12 | 25 | LTC-12 | 3/4" | 19.5 | 24.7 | 25 |
LTCM-13 | 32 | LTC-13 | 1" | 25.0 | 31.7 | 15 |
LTCM-14 | 40 | LTC-14 | 1-1/4" | 33.5 | 39.7 | 6 |
LTCM-15 | 50 | LTC-15 | 1-1/2" | 38.0 | 49.7 | 6 |
LTCM-16 | 63 | LTC-16 | 2" | 49.5 | 62.7 | 4 |
Suitable flexible conduits:
- VJ type of vacuum jacketed flexible conduit
- LT type of liquid-tight flexible conduit
- FM type of flexible metallic conduit
