Product Name:    10 head multihead weigher for feeding control,

multihead weigher machine

Model: JW-A10







1. Application



      * It is suitable for counting project, such as pepper, fruit, jelly, small packs, tomato,potato,onion,large-shell nuts, etc.





2. Features



   *  Program recovery function can reduce operation failures.

   *  No products auto pause function can improve weighing stability and accuracy.

   *  User-friendly help menu in touch screen contributes to easy operation.

   *  100 programs capacity can meet various weighing requirement.

    *  Linear amplitude can be adjusted independently.

   *  Weigh hoppers selected in combination can be set to stagger dump to avoid blocking problem.





3. Mechanical Character



  *  Equipped with both weighing and counting softwares.

  *  Vibration time is automatically adjusted to make sure a good feeding process and improve the

        combination possibility.

  *  Wide V shape feeder pan with an independent photo sensor on its top, feeding process can be effective

       ensured.

   *  Extra PLC helps the motherboard CPU to judge and control the feeding process.





4. Technical Specification



Model	JW-A10
Identify Code	A10-1-8
Single Weighing Range	20-1000g
Accuracy	X(0.5)
Max Speed	50 P/M
Hopper Volume	2.5 L
Control Panel	7.0'' Touch Screen
Options	Dimple Plate /Timing Hopper/Printer/Reject Device
Driving System	Step Motor
Power Requirement	220V/1000W/50/60HZ/10A
Packing Dimension(mm)	1620(L)X1100(W)X1100(H)
Gross Weight	380kg
