| Model Number: | BW-8238 |
|---|---|
| Brand Name: | Bonwin |
| Place of Origin: | China (Mainland) |
| Application: | Locks |
| Smart card type: | 13.56MHz M1 RF card |
| Unlock method: | Card, key, computer |
| Door thickness: | 38~55mm |
| Quiescent Current: | <30 uA |
| Battery: | 4pcs 1.5V |
| HS Code: | 83014000 |
| Certificatio: | CE FCC ISO |
| After Sale Service: | Yes |
| Product Name: | Evergood Quality Intelligent Interlock Door Lock |
Quick Details
Specifications


Evergood Quality Intelligent Interlock Door Lock
Features
1.Service request function -- provide the SOS enmergency calls check out, clea,DND,wait five finds of function of the service request.
2.SOS emergency call -- Once the guest pressthe switch, management computer real-time received alarm signal.
3.Room statues Real-time monitoring -- real time see the room statues.
4.Classification management -- totally 7 kinds of card with different functions and rights.
5.Time limited function -- any card can be set to open during certain time period. The card is invalid overtime.
6.The record function -- record the entry and exit info. It can save 1000pcs records.
7.The function of avoiding disturbing -- guest locked inside of room, only the emergency card / manual key can open lock.
8.Alarm function -- the lock will appears the alarm if door lock close well or back up battery lower than 4.8V.
Parameter Sheet
|
Chip Level |
Technical Grade |
|
Power |
LR6 (AA)battery x 4pcs |
|
Woring temperature |
-10°C ~ 60°C |
|
Static current |
< 30uA |
|
Working current |
< 120mA |
|
Open lock time |
6 seconds |
|
Working humidity |
15~95% RH |
|
Low Power alarm |
4.8V+3% |
|
Unlock records |
At least 200 pcs Unlock records |
|
Door not closed alarm |
Lock will voice if the door not be closed well |
|
Lasting quality |
More than 100000times |
|
Use Life |
10 years |
|
Accepted for door thickness |
38~55mm |
|
Recommend door thickness |
42~45mm |
|
Content |
Front/Back panel,mortise,cylinder,keyx2,battery-pack,manual/Strike |
|
Lock Weight |
3~3.8kg |
