| Model Number: | CFP2-100G-LR4-10 |
|---|---|
| Place of Origin: | China (Mainland) |
| Package: | CFP2 |
| Data rate: | 100G |
| Wavelength: | 1295nm 1300nm 1305nm 1310nm |
| Reach: | 10km |
| Working tempreture: | 0-70 centigrade |
| Power disspation: | below 6w |
Quick Details
Specifications
PRODUCT FEATURES
Compliant with 100GBASE-LR4
Support line rates from 103.125 Gbps to 111.81 Gbps
Integrated LAN WDM TOSA / ROSA for up to 10 km
reach over SMF
Digital Diagnostics Monitoring Interface
Duplex LC optical receptacle
No external reference clock
Single 3.3 V power supply
Case operating temperature range:0°C to 70°C
Power dissipation < 6W
APPLICATIONS
Local Area Network (LAN)
Data Center
Ethernet switches and router applications
STANDARD
Compliant to IEEE 802.3ba
Compliant to CFP MSA CFP2 Hardware Specification
Compliant to CFP MSA CFP2 Management Interface Specification
Compliant with 100GBASE-LR4
Support line rates from 103.125 Gbps to 111.81 Gbps
Integrated LAN WDM TOSA / ROSA for up to 10 km
reach over SMF
Digital Diagnostics Monitoring Interface
Duplex LC optical receptacle
No external reference clock
Single 3.3 V power supply
Case operating temperature range:0°C to 70°C
Power dissipation < 6W
APPLICATIONS
Local Area Network (LAN)
Data Center
Ethernet switches and router applications
STANDARD
Compliant to IEEE 802.3ba
Compliant to CFP MSA CFP2 Hardware Specification
Compliant to CFP MSA CFP2 Management Interface Specification
