Specification

Platform length:3000mm
Platform height:270mm
Platform width:600mm
Pulling arm working range:135°
Pulling post working range:180°
Main cramp working range:0-1500mm
Pulling tower height:1600-2320mm
Hydraulic max pressure:70MPA
Pneumatic pressure range:0.5-0.8mpa
Cylinder max pulling pressure:10T
Total weight:345kg

Remarks:

1.Heigh of single-jaw main clamp could be adjusted,and the jaw can turn in 360°

2.with Moving wheels

3. 10T high pressure cylinder

4.Supporting and fixing system.Before main clamp installing,turing bolts make wheels get off the groud

5.Pneumatic hydraulic pump

6.Heavy duty down  pullay assembly
