| Brand Name: | OEM/Beyondopto |
|---|---|
| Wavelength: | 1310/1550 |
| Data Rate: | 10G |
| warranty: | 3years |
| Connector: | LC/SC/ST |
| Model Number: | BY-DVI-K43 |
| Place of Origin: | China (Mainland) |
| Wavelength: | 850nm & 1310nm |
| Distance: | 0~550M (MM) / 0~20KM (SM) |
| Output video: | DVI 1.0 |
| Input signal DDC: | 5V P-P (TTL) |
| Input Power: | 5 V DC |
| Net Weight: | 800g per pair |
| Case material: | Aluminum |
| Operating humidity: | 0 ~ 95% (non-condensing) |
Quick Details
Specifications
SPECIFICATION
Opitcal:
Wavelength |
850nm & 1310nm |
Output Power |
-8~-3dBm |
Optic fiber |
50/125u multimode, 62.5/125u multimode, 9/125u single mode |
Rx sensitivity |
-22dBm |
Optical connector |
4 x LC |
Distance |
0~550M (MM) / 0~20KM (SM) |
Video:
DVI Input/Output | ||
Output video |
DVI 1.0 | |
Input video signal |
0.51.0V P-P | |
Input signal DDC |
5V P-P (TTL) | |
Connector |
DVI-I | |
General: | ||
Input Power |
5 V DC | |
Power consumption (maximum) |
2W(max) | |
Operating temperature |
-20C to 70C | |
Storage temperature |
-40C to 85C | |
Operating humidity |
0 ~ 95% (non-condensing) | |
Net Weight |
800g per pair | |
Case material |
Aluminum | |
