| Type: | Labeling Machine |
|---|---|
| Automatic Grade: | Semi-Automatic |
| Packaging Material: | Glass,Metal,Paper,Plastic,Wood |
| Packaging Type: | Bags |
| Application: | Beverage,Commodity,Food,Medical |
| Condition: | New |
| After-sales Service Provided: | No overseas service provided |
| Dimension(L*W*H): | (L)1459mm (W)796mm (H)1400mm |
| Model Number: | LT-400 |
| Brand Name: | AutoPack |
| Place of Origin: | Taiwan |
| Power: | Single Phase 110/220VAC |
| Voltage: | 50/60Hz |
| Driven Type: | Electric |
| Labeling Speed: | 40~150 pcs/ min |
| Accuray: | +-1mm |
| Label Length: | 10~250 mm |
| Label Width: | 10~100mm |
| Label Roll: | Inner diemeter 75mm Outer diemeter 300mm |
Quick Details
Specifications
FEATURES:
- Stepper Motor for fast and accurate labeling performane
- Height and angle are adjustable
- Controlled by Microprocessor, LED display
- Label Count Down feature/ Production Run Counter
- One Touch label set and potitioning
- Modular design for easy maintenance/ Quick and easy Changeover
- in Line Application or Independent Operation
- Optium Sensing System offer the most accurate position
- Sanitary Stainless Steel Frame
- Heavy Duty Construction
OPTIONS:
- Servo Motor: Labeling Speed at 40 Meter / Min
- Touch Screen Control System with Job Memory
- Stainless Cabinet Type
- Hot Stamping Coding Machine(PE-200, PM-200)/ Ink jet printer
- Passive Top Pressing Belt: for Slim Product (Suggested)
- Friction Flat Carton Feeder
- LION LDR2100 Clear Label Sensor
SPECIFICATIONS:
- Stepper Motor Driven
- Labeling Speed: 40~150 pcs/ min
- Accuray: 1mm
- Label Length: 10~250mm
- Label Width: 10~100mm
- Label Roll: Inner diemeter 75mm Outer diemeter 300mm
- Power: Single Phase 110/220VAC, 50/60Hz
- Machine Dimensions: (L)1459mm (W)796mm (H)1400mm
