| Type: | Labeling Machine |
|---|---|
| Automatic Grade: | Automatic |
| Packaging Material: | Paper |
| Packaging Type: | Bags |
| Application: | Chemical,Commodity,Food,Medical |
| Condition: | New |
| After-sales Service Provided: | No overseas service provided |
| Dimension(L*W*H): | (L)1500mm (W)840mm (H)1423mm |
| Model Number: | LTB-350 |
| Brand Name: | AutoPack |
| Place of Origin: | Taiwan |
| Power: | Single Phase 110/220VAC |
| Voltage: | 50/60Hz |
| Driven Type: | Electric |
| Accuray: | +-1~1.5mm |
| Label Length: | 10~250 mm |
| Label Width: | 10~100mm |
| Label Roll: | Inner diemeter 75mm Outer diemeter 300mm |
Quick Details
Specifications
Features
- Height and angle of top applicator are adjustable
- Horizontal wrap station makes label well attached
- Two copies applicators with individual switch, able to turn them on/off separately
- Controlled by PLC, touch screen display Output counter
- Adjustable labeling and conveyor speed
- Memory slot, easy to recall the recipe Optimum sensing system offers the most
- Modular design for easy maintenance, quick and easy changeover
- in line application or independent operation
- Accurate position
- in line application or independent operation
Options
- Top pressing sponge/roller for slim products
- Motorized in-feed/collection turntable
- Product feeder/collector
- Mitsubishi PLC and HMI Servo Motor Turnkey linkage with filler, capper, labeler and other in-line systems
- LION LDR6300 clear label sensor
Specifications:
- Driven by stepper motor(linear speed: 12M/min)
- Accuracy: ±1-1.5mm
- Label Length: 10-250 mm, Label Width: 10-100mm
- Label Roll: inner diameter 75mm, outer diameter 300mm
- Power: single phase 110/220VAC, 50/60Hz
- Machine Dimensions: (L)1500mm (W)840mm (H)1423mm (for reference only, the real drawing should be considered as final.)
