20-30 tons Brand New SHACMAN 6X4 Dumper

Company information:
We're one professional manufacturer which refitting special truck and trailer in China, established in 1969, more than 40 yrs producing experience, a growing enterprise with endless innovations and development. Our corporation mainly specializes in the various semi trailers and special vehicle related business, such as dump truck, tanker trailer, concrete mixer truck, and etc. Also, our business line ranges from the research, development, and design to the manufacture and sales for other automobile accessories, especially for axles and hydraulic cylinders. We're one of the earliest company to get the approval of the ISO, CCC and Compulsory Product Certification Enterprises. We have exported more than 30 countries from 2005.Looking forward to your visiting or calling.


We keep good relations with main truck manufactrers in China. And we can supply all brands dump truck made in China. HOWO, SHACMAN, BEIBEN, DONGFENG, SINOTRUK, BEIBEN, FOTON, C&C, and so on. More details for these trucks, feel free to contact us please.


SHACMAN Brand New 25 Tons Tipper Lorry
20-30 Tons SHACMAN Dump Truck
6x4 shacman dumper price
1.Payload:20,25,30MT
2.STEYR engine, EURO2/3
3.Engine:336,375,420
4.high quality


Delong 6x4  shacmandumper price
1.Payload:20,25,30MT
2.STEYR engine, EURO2/3
3.Engine:300,336,375,420hp
4.Cabin: MAN cab(normal lengthen series extra widthen with flat head, single sleeping

Main parameter:
Engine
Engine brand: Steyr (Weichai)
Engine model: WD12.420 4200HP Euro II
Engine type: Diesel 4-stroke direct injection engine, 6-cylinder in-line with water cooling, turbo-charging & intercooling
Displacement: 11.596 liters
Max. Output: 420HP@2200rpm
Max torque: 1760NM@1300-1600rpm
Bore/Stroke(mm): 126/130
Specific fuel consumption: 198g/Kwh

Gear box
Gear box: Fuller 9JS180-B
Clutch: 430 Diaphragm type
Steering: ZF technology

Tyre
Tyre: 12.00R24
No. Of tyre: 10+1spare
Front axle: Steyr 6.5 ton front axle
Rear axle: MAN technology 16 ton double reduction driving axle
Spring: 12/14
Fuel tank capacity (L): 380
Max. Speed (km/h): 77
Kerb. Mass: 14200kg
Total mass: 30700kg
Wheel base (mm): 3800+1350
Front overhang (mm): 1525
Rear overhang (mm): 2054
Front track (mm): 1939/1939
Rear track (mm): 1860/1860

Approach angle: 20 degree
Departure angle: 28 degree
Dimension (mm): 8875x2490x3450


Body

Inner size(mm):	5800x2300x1500
Capacity:	20.01CBM
Thickness of body steel(mm):	Floor 8 mm side & back 4mm
Tipping type:	Front tipping type
