| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | 2 years |
| Certification: | CE,CCC,ISO |
| Weight: | 600KG |
| Dimension(L*W*H): | 1800*2200*1800mm( W*H*D) |
| Power(W): | 32KW |
| Voltage: | 380V |
| Model Number: | TG-TC4 |
| Brand Name: | TARGET |
| Place of Origin: | China (Mainland) |
| Coating: | Powder Coating |
| Substrate: | Steel |
| Type: | Powder Coating Booth |
| Condition: | New |
Quick Details
Specifications
Customize different curing oven size accorditing to customers' product and requirement.
Features:
1. Heating: PID+S. S. R
2. Temperature controller: PID microcomputer control
3. Inner wall : SUS#304 stainless steel
4. Recirculation: Air mandatory recycling levels
5. New High Temperature long axis motors
Specifications:
|
Model |
TG-TC3 |
TG-TC4 |
TG-TC5 |
|
|
Inside chamber size W*H*D(mm) |
1200*1500*800 |
1600*1800*1200 |
1800*2200*1800 |
2500*2500*3500 |
|
Total power |
16 Kw |
26 Kw |
32 Kw |
66 Kw |
|
Panel |
Outer wall : A3 galvanized steel, Electrostatic spraying Inner wall : SUS#304 stainless steel The middle with 150mm thickness rock wool board insulation layer |
|||
|
Heating system |
Stainless steel electric heating pipe . 8(13,16,33) units*2kw , Max. 300 ℃, Heating time : 20-40 min (200-300℃) Voltage : 220v, 380v, 415 , 50/60HZ |
|||
|
Tempe. Control accuracy |
±1°C |
|||
|
Temp. -range |
Rm. Temp~300℃ |
|||
|
Temp. Uniformity |
±2°C |
|||
|
Heating control system |
PID+S. S. R. |
|||
|
The thermostat |
PID microcomputer control, automatic constant temperature, temperature quickly compensation function |
|||
|
Circulation system |
1 set , 0.75Kw (1.1Kw) high-temperature fan |
|||
|
Control system |
Temperature alarm; The sensor system, Stop button; Process setting system: temperature stop automatically . |
|||
|
Accessories |
Complete seal device, door , lock . etc. |
|||
