Introduction:



With collision-resistance processing algorithm, plug & play USB and cursor outputs available, users don't need



to do any programming. It is compatible with ISO15693, ISO18000-3M3 and ISO14443A transponders.



Technical Specification:

• Operating Frequency: 13.56Mhz

• Support Protocols: ISO15693, ISO18000-3M3 and ISO14443A

• Support Labels: Mifare S50/70, Ultralight / Ultralight C / Ultralight EV1, NTAG21x, I code sli/I code slix/I

• code slix2; TI tag-it HF plus/TI tag-it HF pro/tag-it HF standard

• Be capable of reading lots of label support the same protocol simultaneously

• Reading Distance: in best condition ,i code tag approximate 30cm

                                  Mifare tag approximate 18 cm

• Communication Interface: Plug & play USB, curse output (set through software)

• Power Supply: 5V DC

Physical Parameters:

• Outline Dimension: 25*22*0.2(cm) , antenna: 18.8x14.6 cm



• Weight: 150g

Environmental Parameters:

• Operating Temperature: 0℃~60℃

• Storage Temperature: 0℃~75℃

• Relative Humidity: 5%-80% RH
