| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | 12 months |
| Voltage: | 220/380/440V |
| Brand Name: | HENGBON |
| Condition: | New |
| Model Number: | 1575 |
| Place of Origin: | China (Mainland) |
| Processing Type: | Paper Slitting and Rewinding Machine |
| Product Type: | Paper Plate Machine |
Quick Details
Specifications
Frame of main part:
-Cylinder part: φ 1500mmx1950mm cylinder 1 PC, 450mmx2000mm couch 1 PC, reverse part: 400x2000 support one set. Press part: φ 500mmx2000mm top stone roll 1 PC, 450mmx2000mm rubber roll 1 PC.
-Dryer part: 2500mmx1950mm dryer 1 PC, 500mmx2000mm carrier roll 1 PC.
-Drive way and control part: AC frenquenvy conversion speed.
Pneumatic compression device.
| NO. | Equipmets | Qty (set ) |
| 1575mm Single-cylinder and Single-mesh Double-felt paper machine | 1 | |
| 15 type Vacuum pump | 1 | |
| Suction box | 2 | |
| 5m 3 High consistency hydyapulper(under the transmission) | 1 | |
| 1.8m 2 High frequency vibration sieve | 1 | |
| Φ 380 Refining mill | 1 | |
| Desander (3 pcs) | 1group | |
| Pump (6 inch) | 3 | |
| Pump (4 inch) | 2 | |
| 700Impeller | 4 | |
| Single knife cutting machine | 1 | |
| Bleacher (two coppers, one transmission point) | 1 | |
| Centrifugal screen machine | 1 | |
| 2t Boiler(oil/gas/coal) | 1 | |
| Felt wire two sets |
Packaging: products will packaged according to their shapes, weight, transport distance and transport Modes. Large machines will be packaged in sections. Every part of export machinery will be in standard Export package-seaworthy wooden case, waterproof film, straw rope, carton box etc., which will ensure the intactness of products.
Transportation: products will be transported according to their features and clients's needs. Air, train and Sea transportation are all available.
Perfect service :
1.We can supply technical consulting and feasibility report According to
Client's current condition ;
2. We can make detail design of workshop and whole factory ;
3.We supply complete installation and test machine ;
4.We train client's engineer and worker for free ;
5.We supply spare part with best price ;
