| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | twelve months |
| Weight: | 460kg |
| Dimension(L*W*H): | 1320*900*900mm |
| Power(W): | 2000 |
| Voltage: | 380v |
| Ice Shape: | Flake Ice |
| Model Number: | MIF1T-R4A |
| Brand Name: | ICEMTS |
| Place of Origin: | China (Mainland) |
| Capacity: | 100 per month |
| Condition: | New |
| name: | flake ice machine |
Quick Details
Specifications
ICEMTS commercial flake ice machine feature:
1. Commercial flake ice machine is small-sized products specially designed for clients who need less amount of ice.
2. It has the advantages of small space requirement, easy maintenance and convenient relocation.
3. The components of the flake ice machine are made of stainless steel SUS304, aluminum alloy, and PE that are in good conformance with the international standard HACCP and FDA.
Ice advantages of ICEMTS flake ice machine
1.Irregular ice with size about 40*40mm and thickness around 1.6-2.3mm.
2.The thin ice can be directly used for stirring and mixing refrigerated materials.
3.No acute edges and corners so it will not damage the surface of the cooled object;Ice flakes are as cold as below -8 degrees Celsius.
4.Large contact area and good mobility can ensure their full contact with refrigerated objects to realize good preservation effect.
5.Easy to crush and mold.
6.The flake ice making machine is small-sized,light and convenient for use anytime.
Technical Parameters of the flake ice machine
|
Parameters |
Technical data |
||||
|
Daily output(T/24H) |
0.3T |
0.5T |
1T |
1.2T |
1.5T |
|
Necessary cooling capacity(kw) |
2 |
3.3 |
5.6 |
6.6 |
9.8 |
|
General power(kw) |
1.95 |
2.49 |
4.22 |
4.72 |
6.75 |
|
Compressor input(kw) |
1.59 |
2.2 |
3.8 |
4.3 |
6.33 |
|
Power of reducer(kw) |
0.25 |
0.18 |
0.18 |
0.18 |
0.18 |
|
Cooling mode |
Air cooling |
Air cooling |
Air cooling |
Air cooling |
Air cooling |
|
Water inlet |
1/2" |
1/2" |
1/2" |
1/2" |
1/2" |
|
Ice thickness |
1.5mm~2.2mm |
1.5mm~2.2mm |
1.5mm~2.2mm |
1.5mm~2.2mm |
1.5mm~2.2mm |
|
Weight (w/o ice storage bin) |
190kg |
300kg |
450kg |
460kg |
480kg |
|
Dimension(mm) |
1050*700*700 |
1280*800*800 |
1320*900*900 |
1320*900*900 |
1400*950*1000 |
|
Dimension (with storage bin) |
1050*800*1480 |
1280*1085*1850 |
1320*1185*2100 |
1320*1185*2100 |
1500*1420*2300 |
Welcome visit us or inquiry us, we make customized ice flake machine as per your request, special voltage is available, split type machine, air / water cooling etc.
