Model: ZAY7045FG

Main specifications(mm):;working table can swivel
Max drilling capacity(mm): 45

Max tapping capacity(mm): M12

Max face milling capacity(mm): 80

Max end milling capacity(mm): 32

Max. distance from spindle nose to table(mm): 450

Distance from spindle axis to colum(mm): 285

Spindel travel(mm): 130

Spindle taper: MT4

Step of spindle speed: 6

Range of spindle speed(r. p.m): 80~1250    /  95~1500

Speed of automatic feeding spindle feed: 6
Automatic feeding amount of spindle: 0.06~0.3

Swivle angle of headstock(Headstock perpendicular): ± 90°

Table size(mm):   800*240    /      700*240

Forward and backward travel of table(mm): 175

Left and right travel of table(mm): 500/400

Motor power: 1.5kw(2Hp)

Vol /freq: As customer' s requirement

Net height(Wthout stand) (mm): 1060

Net weight(kg): 315
