ITEM Z5032C/1  Z5040C/1  Z5045C/1
Max. Drilling Capacity: 32mm/40mm/45mm
Spindle Taper: M. T. 3 or R8/M. T. 4/M. T. 4
Spindle Travel: 130mm/130mm/130mm
Step of Spindle Speed: 6/6/6
Range of Spindle Speed:
50Hz: 80-1250 r. P. M/80-1250 r. P. M/80-1250 r. P. M
60Hz: 95-1500 r. P. M/95-1500 r. P. M/95-1500 r. P. M
Min. Distance from Spindle Axis to Column: 283mm/283mm/283mm
Max. Distance from Spindle Nose to Worktable: 725mm/725mm/725mm
Max. Distance from Spindle Nose to Stand Table: 1125mm/1125mm/1125mm
Max. Travel of Headstock: 250mm/250mm/250mm

Swivel Angle of Headstock(horizontal/perpendicular): 360/+ -90 360/+ -90 360/+ -90 degree
Max. Travel of Worktable Bracket: 600mm/600mm/600mm
Worktable Size of Avaliablity: 380x300mm/380x300mm/380x300mm
Swivel Angle of Table Horizontally: 360/360/360 Degree
Table Leaned: + -45/+ -45/+ -45 degree
Size of Stand Worktable of Avaliability: 417x416mm/417x416mm/417x416mm
Motor Power: 0.75KW(1HP)/1.1KW(1.5HP)/1.5KW(2HP)
Voltage/Frequency: as customer's requirement/as Customer's requirement/as customer's requirement
Speed of Motorl: 1400 r. P. M/1400 r. P. M/1400 R. P. M
Net Weight/Gross Weight: 430kg/480kg; 432kg/482kg; 435kg/485kg
Packing Size: 1850x750x1000mm/1850x750x1000mm/1850x750x1000mm
Loading Amount: 18PCS/20'container; 18PCS/20'container; 18PCS/20'container
