Product Main

Quick Details

Brand Name:	Huamo
name:	PP Membrane Pleated Filter Cartridge for Pre-Filtration Or RO System,
Material:	PP
application:	Pre-filtration
Type:	Pleated filter cartridge
Model Number:	PPL
Place of Origin:	China (Mainland)
Media:	Polypropylene
Support layer:	Polypropylene
Core/Cage/End adaptor:	Polypropylene
Sealing Method:	Thermal bonding
Micron Rating:	0.1,0.2,0.45,0.65,1,3,5...um
Application:	Pre-filtration for RO system, DI water
Shipping:	By sea/DHL/UPS/TNT/Fedex
MOQ:	1 pc
Payment:	TT/Western union/Paypal
Length:	5",10",20",30",40"

Specifications

PP Membrane Pleated Filter Cartridge
Material of Construction		Filter Media	Polypropylene
		Support Layers	Polypropylene
		Micron Rating	0.1,0.2,0.45,0.65,1.0,2.0,3.0,5.0,10,30,50,70,100um
		Inner Core	Polypropylene
		Outer Cage&End Cap	Polypropylene
		Seal Method	Thermal Bonded, No Adhesives
		O-ring/Gaskets	EPDM, Silicone, Buna, Viton
Cartridge Dimensions		Outer Diameter	69mm(2.75")
		Inner Diameter	28mm(1.10")
		Length(Based on DOE End Cap)	5", 10", 20", 30", 40"
		Filtration Area(m2)	0.65m2 per 10"
Operating Conditions		Normal Operating Temperature	up to 65(140)
		Max Operating Temperature	80(176) at P1.0 bar(14.5psi)
		Forward Flow Direction	5.1 bar(75psi) at 25(77)
		Reverse Flow Direction	2.1 bar(30psi) at 25(77)
		PH Value Compatibility	1-14
		Sterilization Temperature Time	Steam Sterilization for 30 minutes at 1212, 100 cycles, Autoclave 30minutes(optional)
Cartridge Safety		Endotoxin	0.25 EU/ml
		Extractables	0.03g/10"
