| Application: | Metering |
|---|---|
| Pressure: | Low Pressure |
| Fuel: | electric |
| Standard or Nonstandard: | Standard |
| Power: | Electric |
| Usage: | pumping fluid |
| Structure: | Gear Pump |
| Theory: | Mixed Flow Pump |
| Model Number: | BT/L |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Instruction:
Peristaltic Pump iPump2L-B drive achieve flow rates from 0.0001 to 825 mL/min. large 128 x 64 graphic LCD displays running menu and parameters setting menu. Data of flow rate and speed (rpm) being showed same time on screen. Calibration function ensure accuracy of flow rate. Standard external control and RS485 communication interface.
Specifications:
-Flow range:0.0001-825ml/min
- Speed: 0.1to 200.0 rpm, reversible
- Speed resolution: 0.1 rpm
- Speed control: Rotary encoded switch with membrane keypad
- Display: large 128 × 64 graphic LCD displays current running status
- External Control: Start/stop and cw/ccw control, 0 to 5 V, 0 to 10 V, and 4 to 20 mA speed control
- Communication interface: RS485
- Power supply:wide voltage range AC 90V-260V 50/60 Hz
- Power consumption: <35 W
- Operating condition: Temperature 0 to 40 °C, Relative humidity < 80%
- Dimensions (L × W × H): 202 × 153 × 227 (mm)
- Drive weight: 3.7kg
- IP rating: IP 31
Functions and Features:
- Display can switch between flow rates and speed
- Calibration function ensure more accurate data of flow rate
- Graphic LCD together with rotary encoded switch makes it user-friendly and easy to use
- Higher torque to accept more pump heads and more channels
- RS485 communication interface available. Offering communication protocol and customizing software according to customer's requirements.
- Speed resolution: 0.1 rpm
- Speed control: Rotary encoded switch with membrane keypad
- Display: large 128 × 64 graphic LCD displays current running status
- External Control: Start/stop and cw/ccw control, 0 to 5 V, 0 to 10 V, and 4 to 20 mA speed control
- Communication interface: RS485
- Power supply:wide voltage range AC 90V-260V 50/60 Hz
- Power consumption: <35 W
- Operating condition: Temperature 0 to 40 °C, Relative humidity < 80%
- Dimensions (L × W × H): 202 × 153 × 227 (mm)
- Drive weight: 3.7kg
- IP rating: IP 31
Functions and Features:
- Display can switch between flow rates and speed
- Calibration function ensure more accurate data of flow rate
- Graphic LCD together with rotary encoded switch makes it user-friendly and easy to use
- Higher torque to accept more pump heads and more channels
- RS485 communication interface available. Offering communication protocol and customizing software according to customer's requirements.
