Specifications:

Bench length: ------------------------------4200mm

Bench width: --------------------------------950mm

Working height: ----------------------------260--1600mm

Post Max. Pulling tension: ----------------95KN (10tons)

Rated voltage: ------------------------------220/380V

Post working range: -----------------------360°

Max. Lifting weight: -----------------------3500kg

Total weight: -------------------------------1800kg

Features:

1.the bench welded with cold high alloy rectangular tube, full plate and have high intensity.

2.the vertical lifting bench can lift vertically, and can be used as a scissor lift. the working range from 260mm to 1600mm high.

3.Frame basement can be folded up, four base wheel can be movable., when the vehicle is fixed on the platform, move them together to a specific position according to the maintenance need.

4. Unique ramps make the vehicle go up easily and quickly. the ramps are also could be used as support base for car wheels, which help to fix the clamps during repair.

5. Two flexible moving pulling towers can be fixed firmly and stretched at varied direction. the imported hydraulic system with strong power and long working life.

6. All the clamps and tools are through forging, integral modulation and high frequency quenching heat treating, which have long lifetime and can repair almost any distortion.

7. Main clamp jaw with patient can fix auto body, main clamp and cross-beam together with one screw, Scientific design, firm fixing and quick operation improve working efficiency greatly.

8. the most advanced measuring system, no interrupted ponit, operated conveniently.

9.Perfect after sales service guarantees customers' satisfaction.

Our services:

1. OEM ODM service.

2. Customized service: the color and size of the product can be customized.

3. Two Years Quality warrant service, during the period spare part supplied free if you pay for shipping.

4. Professional team supply service for life long time.

FAQ:

1. Can You make the machine according to request?

2. What's the Min. Order for your company machine?

1 set. Normally one standard model need 7 workdays.

3. OEM Is available?

Yes, we can put your logo on the machine .and make the machine structure as your design request.

4. What kind of measuring system do you have?

We have the two dimension measuring,three dimension measuring and CHEIF electric measusing system for your choice.

5. What's the advantage of your company?

We have exported our machine to more than 50 countries. and have a Professional team service for yo.We guarantee give feedback within 24 hours. Oversea service will supply uopn requests.
