| Printing
Size |
2500mm*1300mm |
| Print Head(s) |
6pcs TOSHIBA print heads,
CE4 series 636holes*2listl; smallest ink drop 5pl |
| Printing
Colors |
C, M, Y, K, LC, LM+W |
| Printing
Height |
100mm |
| Printing
Weight |
Non-destrutive Precision
Weight100KG |
| Print
Speed |
Production Mode:300x1200dpi
36 sq/hr |
| High
Quality Mode:300x1800dpi 18m sq/hr |
| High
Accuracy Mode:300x2400dpi 9m sq/hr |
| Ink System |
UV Curable Ink(C,M,Y,K,LC,LM+W) |
| Automatic
Cleaning System |
Automatic
Cleaning Function |
| Print Head(s)
Technology |
Piezo Inkjet Printing
Ink |
| Ink Cartridge |
Continuous
Ink offering/Capacity: 1000ml |
| Power Supply |
220V/3000W, 50HZ/60HZ |
| Applied Materials |
Ceramic,
Acrylic, Wood, Craft, Painting, Glass, Metal,Crystal,Leather,PVC,ABS etc. |
| Curing System |
LED
Light Curing System |
| Color
Management |
Admitted
to International ICC Standard, with Curve Line Function. |
| Image Format |
TIFF,JPEG,Postscript 3,EPS,PDF
Etc |
| Operating
Platform |
Vacuum Adsorption Platform
(Alloy Aluminum Honecomb) |
| USB USB
Connector |
USB
2.0 Connector/USB3.0 Connector |
| Operating
Environment |
Temperature:20-50℃,Humidity:40-60%,Dust-free room |
| Guide
Rail |
Square Linear Guide Rail |
| RIP Software
Output |
Ultraprint |
| N/W. |
1400KG |
| Equipment
Size: |
1450*4402*1388(mm) |
