| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Structure: | Plate Heat Exchanger |
| Place of Origin: | China (Mainland) |
| Condition: | New |
Quick Details
Specifications
We have hundreds of types of plate and gasket for your choice, with the most complete range, Perfect quality and irresistible prices.
Used for maintenance and production
Plate material: SS304, 316L, Titanium, Nickel, 254Mo, Hastelloy
Plate thickness: 0.5mm, 0.6mm
Gasket material: NBR, EPDM, FPM, Silicone rubber
Food-grade Material and other materials suitable for special working condition, like elevated Or low temperature conditions, are also available.
Material |
Applicable Media |
SS 304 |
Pure water, River water, edible oil, mineral oil |
SS 316L |
Pure water, River water, edible oil, mineral oil |
Titanium |
|
Nickel |
High temperature or high concentration caustic soda |
Mo |
Dilute sulphuric Acid, inorganic aqueous solution |
Hastelloy |
Concentrated Sulphuric acid, hydrochloric acid, phosphoric acid |
Material |
Temp. |
Applicable Media |
NBR |
-15~+110 |
Pure water, sea Water, salt water, mineral oil |
HNBR |
-15~+140 |
High temperature Water or mineral oil |
EPDM |
-25~+170 |
Hot water, water Vapour, acid, alkali |
F.Viton G |
-5~+180 |
Acid, alkali fluid |
Silicone Rubber |
-65~+250 |
Low temperature and dry heat resistant |
Asbestos |
-5~+250 |
Food, oil, fat, Alcohol |
