Maincomponents
Worldfamousbrandrefrigerationpartsare employedforall products: Bitzer ECOLINE series semi-hermetic pistoncompressor;
Coppertube &aluminumfin typheat exchanger; Builtinwaterproofterminalbox;
3.Modelcode
4. Speciations
4.1Aircooledmiddleand high temperature units
For refrigerant R22
|
Model |
JZBF02M |
JZBF03M |
JZBF03M |
JZBF03M |
JZBF04M |
JZBF05M |
||
|
Compressor model |
2GES-2 |
2FES-3 |
2EES-3 |
2DES-3 |
2CES-4 |
4FES-5 |
||
|
Room Tem ( ℃) |
-10℃ ~5 ℃ |
|||||||
|
Power supply |
380V/3P/50 HZ |
|||||||
|
condnsr |
Fan Qty |
1 |
1 |
2 |
2 |
2 |
2 |
|
|
Fan Voltage |
380 |
380 |
380 |
380 |
380 |
380 |
||
|
Fan input(W) |
180×1 |
180×1 |
140×2 |
140×2 |
180×2 |
180×2 |
||
|
ca acity&input |
Te-5 ℃ |
Cap(W) |
4190 |
5150 |
6450 |
7710 |
9490 |
10110 |
|
input(KW) |
1.76 |
2.14 |
2.48 |
2.97 |
3.65 |
3.83 |
||
|
Te-10 ℃ |
Cap(W) |
3420 |
4200 |
5230 |
6270 |
7740 |
8180 |
|
|
input(KW) |
1.65 |
2.0 |
2.3 |
2.76 |
3.4 |
3.56 |
||
|
Te-15 ℃ |
Cap(W) |
2770 |
3380 |
4180 |
5020 |
6230 |
6520 |
|
|
input(KW) |
1.53 |
1.86 |
2.11 |
2.53 |
3.12 |
3.52 |
||
|
ecto |
Gas Dia(mm) |
φ16 |
φ16 |
φ22 |
φ22 |
φ22 |
φ22 |
|
|
Liquid out(mm) |
φ10 |
φ10 |
φ12 |
φ12 |
φ12 |
φ12 |
||
|
Overall size |
A (mm) |
620 |
620 |
960 |
960 |
1060 |
1300 |
|
|
B (mm) |
650 |
650 |
680 |
680 |
680 |
750 |
||
|
C (mm) |
560 |
560 |
460 |
510 |
720 |
670 |
||
|
Installsize(a×b)(mm) |
580×350 |
580×350 |
920×380 |
920×380 |
1020×380 |
1260×410 |
||
