| Type: | TFT |
|---|---|
| Model Number: | LMT068 |
| Brand Name: | TOPWAY |
| Place of Origin: | China (Mainland) |
| Size: | 6.8'' |
| Resolution: | 1366x480 |
| Interface: | LVDS, VGA and RS2322 |
| Application: | Industrial area |
Quick Details
Specifications
Main features:
6.8'' size, strip display, 1366(RGB)x480 resolution
Active area:163.92*55.44mm
VGA, LVDS and RS232 interface optional
Signal power supply
High reliable
Operating temperature: -20 to 70oC,
Storage temperature: -30 to 80oC
Resistive touch panel optional
| Item | Description |
| Product Name | Industrial Panel 6.8 Inch (LMT068) |
| Model No. | LMT068 Series |
| Number of dots | 1366*3(RGB)*480 |
| Outline Dimension(mm) | 195.0 X 69.9 |
| Active Area(mm) | 163.92 X 55.44 |
| Viewing Angle: T/B/L/R | 50/70/70/70 |
| Brightness(CD/m2) | 500 |
| Contrast Ratio | 500 |
| Backlight | LED |
| Power supply | 5V |
| Color Depth | 256K |
| Interface | VGA, LVDS |
| RS232 | |
| Touch panel | 4-wire Resistive |
| Operating Temp | -20o C~70o C |
| Storage Temp | -30o C~80o C |
