MQSPAC STRETCH WRAP Features

1)Exclusive design by MQSPAC;

2)Power pre-stretch  film carriage,ratio250%,film saving;

3)Cerificate:ISO9001/CE, meet the requirements of international standards;

4) Adopt international advanced manufacturing technology,  imported parts , components, electrical components;

5) PLC automatic program control, simple and convenient operation, low fault rate, low cost;

6) Auto imported height photoelectric detection, automatic height limit wrapped package;

7) 9 layer coated membrane way choice, to meet various requirements;

8)Auto height detection,turntable home position,forklift sockets for easy moving;

9)Strongly safety protection;

10) Dual limit switches on the top&bottom to provide better safety protections;

11) Film under the bottom of the rack configuration anti-collision device, protective film carriage, to ensure the safety of staff

12) film carriage ratio of 250%, for customers to save the packaging cost, improve the efficiency of the packaging, the best choice of packaging standardization;
13)Using this  mqspac wrapping machine to replace artificial, will provide a standard, effective, safe wrap film packaging, reduce the loss of products during the process of transportation cost

Mqspac stretch wrap with M type Specification

1.Turntable  Diameter:       1650mm             optional 1800mm,2000mm

2.Wrapping  Height:             2100mm

3.Loading  Weight:               650kg(max)

4.Packing  Speed:                 20-45 pallets/hour

5.Turntable Speed:              0-15rpm,speed variable,turntable soft &soft stop

6.Turntable Height:              90mm                 customized

7.Carriage Speed:                3m/min

8.Control:                              PLC program logic control

9.Working  Mode:             auto/manual

10.wrapping setings:                 wrap cycls/top wraps/bottom wraps/over wrap

11:Product size:                  L×W×H(2710×1680×2300)mm

12:Power:                            1 PH,220/110VAC,2Kw,20A

13.Film type: stretch film thickness 17-35microns, width 450-500mm, paper core76mm, max

      weight 18kgs
